| Categories | not group |
|---|---|
| Brand Name: | JAGUAR automation |
| Model Number: | t8 |
| Certification: | ce |
| Place of Origin: | shenzhen |
| MOQ: | 1 |
| Price: | USD 2000 |
| Payment Terms: | T/T, Western Union |
| Supply Ability: | 100set/month |
| Delivery Time: | 25days |
| Packaging Details: | vacuum packing and wooden packing |
| motor: | Use 200W |
| Speed control method: | frequency control |
| Active roller: | pipe roller |
| material: | 40*20 Galvanized |
| Span: | 2m/phase |
| Up: | L500*Φ25mm |
| Light Tong: | 40*20mm wire slot |
| 1 | Driving system | motor | Use 200W Gear speed reduction motor, Speed rate: 1:40 |
| Speed control method | frequency control,V=1-6m/min | ||
| Active roller | D=160mm seamless steel pipe roller, D=50mm tail roller | ||
| 2 | Line Body Structure | material | stand is made of 40*40*1.5mm FangTong welding, light fixture is made of 40*30*1.5mm FangTong welding, under light with 75*12*80mm glue stepping cup, working height is 750±15mm |
| Span | 2m/phase | ||
| 3 | Transport belt | Width: 500mm, thickness:2mm, Green cover PVC conveyor belt, seamless interface | |
| 4 | Belt support | Up | L500*Φ25mm Galvanized roller bearing support,span 300mm/line |
| bottom | L500*Φ25mm Galvanized roller bearing support,span 200mm/line | ||
| 5 | light | Light Tong | 40*20mm wire slot |
| light | T8 lamp with a single band cover efficient energy-saving lamps, all the way around the configuration. | ||
| 6 | Process Chart | Guide rail | “H”type aluminum profile |
| plate | 1m 1 A4 glue set double side equipped | ||
7 | Wire slot and plug | material | 40*20 Galvanized iron wire slot |
| plug | Two or three outlets (per meter / branch,both side equipped) | ||
| position | Line left-right installation. | ||
8 | size | W=400mm | |
| table | Made of wood plywood surface with green fireproof board | ||
| supporting | 40*20mm Biantong, 1.2mm thickness | ||
9 | Long work table | size | W=400mm,double sides |
| Electrostatic table plate | T15mm board attached to the surface of T2.0mm green anti-static rubber, rubber sealing | ||
| supporting | 40*30 Biantong and tripod support | ||
| 10 | Surface Preparation | Aluminum surface is the original color, Steel surface is computer white with electrostatic paint | |
