Automatic Digital LCD Display Screen Conveyor Metal Detector System JZD-366

Automatic Digital LCD Display Screen Conveyor Metal Detector System JZD-366

Automatic Digital LCD Display Screen Conveyor Metal Detector System JZD-366
Automatic Digital LCD Display Screen Conveyor Metal Detector System JZD-366
Categories Industrial Metal Detector
alarm: audible and visual alarm ,automatic stop
customized support: OEM, ODM, OBM
Brand Name: JUZHUO
conveyor coload: 25kg(customized)
MOQ: 1
waterproof: IP66
certification approval: CE,ISO9001,HACCP
warranty: 1year
type: New
Raw material: SUS304
conveyor speed: 22m/minutes(adjustable)
belt color: customized
Place of Origin: Guangdong, China
Model Number: JZD-366
control panel: LCD display screen
Contact Now
Company Info.
Dongguan Juzhuo Precision Machinery Co., Ltd.
Verified Supplier
View Contact Details
Product List
  • Haven't found right suppliers
  • Our buyer assistants can help you find the most suitable, 100% reliable suppliers from China.
  • And this service is free of charge.
  • we have buyer assistants who speak English, French, Spanish......and we are ready to help you anytime!
Submit Buying Request
  • Product Details
  • Company Profile

Automatic Digital LCD Display Screen Conveyor Metal Detector System JZD-366

Automatic Digital LCD Display Screen Conveyor Metal Detector JZD-366
Product Overview

The JZD-366 is an advanced LCD display intelligent/digital metal detector featuring two-way signal detection circuit technology. It incorporates cutting-edge electromagnetic detection and digital signal processing technology, utilizing the latest DDS (Direct Digital Synthesizer) and DSP (Digital Signal Processor) hardware combined with advanced detecting algorithms, self-study capabilities, and full digital regulating functions for stable and dependable detection performance.

Applications

This digital metal detector is primarily used for detecting metal impurities in various food products including bakery items, pizza, hamburgers, puree, sauce, vegetables, tobaccos, and other applications requiring metal detection. It is designed to operate reliably in challenging environments including high temperature, low temperature, humidity, dry conditions, dust, and dew.

Key Features
  • LCD display control panel with English and Chinese language options
  • Capable of detecting impurities in products packaged with evaporating aluminum
  • Stores up to 100 different product detection parameters for easy product changeover
  • Automatic identification learning functions that efficiently overcome product material effects
  • Detection head utilizes dual channel detecting circle German technology with rectangular aperture (indivisible)
  • ADLINE microprocessor controller system
  • Compliant with IFS standards and certified with HACCP, CE & ISO 9001
  • Strong suppression for product effects in aquatic foods, frozen foods & pickled foods
  • Excellent anti-interference and shock proof capabilities
  • Easy disassembly and convenient cleaning design
Technical Specifications
ParameterSpecification
ModelJZD-366
Inspection Window Width400mm (400mm customization available)
Inspection Height Options100mm, 120mm, 150mm, 200mm, 250mm, 300mm, 350mm, 400mm
Detection Sensitivity - Fe (Φmm)≥0.6, ≥0.8, ≥1.0, ≥1.2, ≥1.5, ≥2.0, ≥2.5, ≥3.0
Detection Sensitivity - Non-Fe (Φmm)≥1.0, ≥1.2, ≥1.5, ≥2.5, ≥3.0, ≥3.5, ≥4.0, ≥4.5
Detection Sensitivity - 304SUS (Φmm)≥1.2, ≥1.5, ≥2.0, ≥2.5, ≥3.0, ≥3.5, ≥4.0, ≥4.5
Alarm SystemAudible and visual alarm with automatic stop
Construction MaterialSUS304 Stainless Steel
Standard Machine Dimensions160cm (L) × 90cm (W) × 100cm (H)
Net Weight330kg (standard size)
Power Supply110V/220V/380V 50Hz/60Hz, 90W
Conveyor Speed25-30m/min (customizable to customer requirements)
Conveyor Height650mm ±50mm (standard, customizable to customer needs)
Note: The sensitivity specifications are measured without bearing any parts. Actual sensitivity may vary depending on product nature and temperature. Automatic rejection equipment can be installed according to customer requirements.
Product Images
JZD-366 Metal Detector front view JZD-366 Metal Detector side view JZD-366 Metal Detector control panel JZD-366 Metal Detector inspection area JZD-366 Metal Detector conveyor system JZD-366 Metal Detector internal components JZD-366 Metal Detector display close-up JZD-366 Metal Detector in operation JZD-366 Metal Detector technical diagram JZD-366 Metal Detector installation view JZD-366 Metal Detector quality certification JZD-366 Metal Detector industrial application JZD-366 Metal Detector maintenance access JZD-366 Metal Detector safety features JZD-366 Metal Detector wiring diagram JZD-366 Metal Detector packaging JZD-366 Metal Detector calibration process JZD-366 Metal Detector user interface JZD-366 Metal Detector production line integration JZD-366 Metal Detector final inspection
