XPM-Φ120×3 Three Head Grinding Machine Laboratory Mineral Sample
Pulverizer
The XPM-Φ120×3 Three Head Grinding Machine is a professional
laboratory sample preparation equipment designed for fine grinding
of mineral, geological and industrial materials. This machine
features a three-head grinding structure that allows three samples
to be processed simultaneously, significantly improving laboratory
testing efficiency.
Key Features
- Three Grinding Heads Design: Processes multiple samples simultaneously for improved laboratory
efficiency
- Uniform Grinding Performance: Optimized grinding structure ensures consistent sample fineness
and analysis accuracy
- Professional Laboratory Application: Specifically designed for mining, geological exploration,
metallurgical testing, chemical analysis, and scientific research
- Stable and Reliable Operation: High-quality motor and transmission system provide smooth
operation with low vibration
- Compact Structure: Small footprint suitable for laboratories with limited working
space
- Easy Operation and Maintenance: Simple operating process with convenient cleaning and component
replacement
Working Principle
The XPM-Φ120×3 three head grinding machine operates through
interaction between grinding bowls and grinding media. After sample
entry, the motor drives the grinding mechanism to rotate. Under
combined effects of pressure, friction and impact force, material
is gradually crushed and ground into fine powder. The three
grinding heads operate simultaneously to achieve efficient and
uniform sample preparation for laboratory testing and analysis.
Technical Specifications
| Item | Specification |
|---|
| Model | XPM-Φ120×3 |
| Product Type | Three Head Grinding Machine |
| Grinding Bowl Diameter | Φ120 mm |
| Number of Grinding Heads | 3 |
| Feeding Size | ≤1 mm |
| Grinding Speed | 220 r/min |
| Motor Speed | 1400 r/min |
| Motor Model | AO2 7124 8/4 |
| Motor Power | 370 W |
| Voltage | 380 V |
| Weight | 130 kg |
| Dimension (L×W×H) | 780×750×500 mm |
| Grinding Method | Dry Grinding |
| Application | Laboratory Sample Preparation |
Applications
- Mining Industry: Ore sample testing, mineral analysis, beneficiation laboratory
experiments, raw material inspection
- Geological Industry: Rock sample preparation, geological exploration testing, mineral
composition analysis
- Metallurgy Industry: Metal ore testing, metallurgical research, laboratory analysis
- Chemical Industry: Material composition testing, chemical laboratory preparation
- Research Institutes: Scientific experiments, university laboratories, quality
inspection centers
Key Advantages
- Three-head design for higher laboratory efficiency
- Uniform grinding results for accurate analysis
- Suitable for various mineral samples
- Stable motor performance and reliable operation
- Compact laboratory-friendly design
- Low noise and easy maintenance
- Ideal equipment for mining and geological laboratories
Quality Control
Each XPM-Φ120×3 grinding machine is manufactured under strict
quality control procedures. Before shipment, equipment performance,
mechanical operation and safety conditions are carefully inspected
to ensure reliable operation after delivery.
Packaging & Shipping
The equipment is packed in strong export wooden cases to prevent
damage during transportation. Packaging features moisture
protection, shock resistance, secure fixation, and suitability for
sea, air and land transportation.
Safety Instructions
- Operators must receive safety training before operation and
carefully read the instruction manual.
- Do not adjust, clean or repair the machine while it is running.
- The electrical system must be properly grounded. Electrical cables
should be installed with insulation protection, and leakage
protection devices should be added according to working conditions.
- According to operating frequency and material conditions, overload
protection devices should be installed to prevent motor overheating
and equipment damage.
- Users should regularly check safety protection devices and ensure
all protective measures meet actual working requirements.
Frequently Asked Questions
What is the main application of XPM-Φ120×3 grinding machine?
It is mainly used for laboratory preparation of mineral, geological
and industrial material samples before analysis.
How many samples can be processed at the same time?
The machine has three grinding heads and can process three samples
simultaneously.
What is the maximum feeding size?
The feeding size should be ≤1 mm.
What materials can be ground?
It can grind ores, rocks, coal, cement, ceramics and various
brittle mineral materials.
Is it suitable for mining laboratories?
Yes. It is widely used in mining companies, geological institutes,
metallurgy laboratories and research centers.
