Durable Fiber Optic Patch Cables SM sc upc outdoor patch cord for Communication Systems

Categories Fiber Optic Patch Cables
Brand Name: HICORPWELL
Model Number: ODVA LC Plug
Certification: IEC 60794-2-10/11
Place of Origin: China
MOQ: 2sets
Price: negotiation
Payment Terms: Western Union, L/C, T/T
Supply Ability: 5000pcs Per Week
Packaging Details: Max 100m/ per reel for 5.0 mm OD cable
Cable Type: SM sc upc outdoor patch cordSM sc upc outdoor patch cord
Connectors: sc upc
Paintcoat Color: Black
Jacket OD: 2MM 3MM
Length: Per Reel.100m -300m
Package: Plastic bags with test report
Add info: Multimode Simplex Steel Armoured Fiber Optic Patch Cord
Fiber Count: Simplex Duplex
  • Haven't found right suppliers
  • Our buyer assistants can help you find the most suitable, 100% reliable suppliers from China.
  • And this service is free of charge.
  • we have buyer assistants who speak English, French, Spanish......and we are ready to help you anytime!
Submit Buying Request
  • Product Details
  • Company Profile

Durable Fiber Optic Patch Cables SM sc upc outdoor patch cord for Communication Systems

Durable Fiber Optic Patch Cables SM SC/UPC Outdoor Patch Cord for Communication Systems

A comprehensive technical and commercial guide for durable Single-Mode (SM) SC/UPC Outdoor Fiber Optic Patch Cables, tailored for communication system deployment with clear specifications, outdoor-specific features, applications, selection criteria, and installation tips.

Key Terminology Clarification
  • SM (Single-Mode): 9/125 μm OS2 fiber (G.652D/G.657A1 common), optimized for 1310nm/1550nm wavelengths, low attenuation, long-haul transmission, no modal dispersion
  • SC/UPC: Square Connector with Ultra Physical Contact polish; push-pull latching, ceramic ferrule, return loss ≥50 dB, insertion loss ≤0.3 dB (premium ≤0.2 dB), widely used in telecom/FTTH
  • Outdoor-rated: UV-resistant jacket, moisture barrier (gel/dry block), wide temperature range, optional armor (steel/Kevlar/FRP) for rodent/crush protection
Technical Specifications
ParameterStandard ValuePremium Option
Fiber typeOS2 9/125 μm (G.652D/G.657A1)G.657.A2/B3 (bend-insensitive)
Wavelength1310 nm / 1550 nm1625 nm (OTDR test)
Insertion Loss≤ 0.3 dB≤ 0.2 dB
Return Loss (UPC)≥ 50 dB≥ 55 dB
Jacket materialLSZH/PE (UV-resistant)Armored LSZH/TPU
Operating temp-40°C to +75°C-40°C to +85°C
Mechanical protectionKevlar reinforcementSteel tube armor+FRP
CertificationsTelcordia GR-1209/1221, IEC 61754, CE, RoHSCPR, NEBS
Outdoor-Specific Durability Features
  • UV & Weather Resistance: LSZH/PE outer sheath prevents sun-induced brittleness; black jackets reduce heat absorption
  • Moisture & Water Blocking: Gel-filled or dry-block longitudinal barriers stop water ingress along the cable core; sealed SC connector boots (IP67 rated) prevent end-face condensation
  • Mechanical Robustness: Kevlar yarn for tensile strength; metal/corrugated armor for anti-crush, anti-rodent; minimum bend radius (static 10× cable OD, dynamic 20× OD)
  • Temperature Stability: No performance degradation in extreme cold/heat, suitable for desert, high-altitude, and frigid regions
Durable outdoor fiber optic patch cable with SC/UPC connectors
Close-up view of SC/UPC connector and cable construction
