| Categories | SFTP CAT7 Cable |
|---|---|
| Brand Name: | ITI-LINK |
| Model Number: | ITI-CT7SF-020 |
| Certification: | UL, ETL, CSA, RCM, TUV, CPR, CE, RoHS |
| Place of Origin: | SHENZHEN |
| MOQ: | 1000pcs |
| Price: | $50-$100 |
| Payment Terms: | T/T |
| Supply Ability: | 1000pcs/day |
| Delivery Time: | 15-45 Days |
| Packaging Details: | Wooden shaft packaging 40*26*20cm Outer box size：42*42*22cm |
| Shielding Type: | CAT7 SFTP |
| Conductor Size: | 23AWG |
| Frequency: | 600MHz |
| Jacket Material: | PVC/LSZH |
| Speed: | Up to 10Gbps |
| Conductor Material: | Copper |
| Jacket Color: | Orange |
| Cable Length: | 1000FT (Bulk) |
| Company Info. |
| Integrity Cable Co., Limited |
| Verified Supplier |
| View Contact Details |
| Product List |
Professional CAT7 SFTP Shielded LAN Cable built with 23AWG solid copper, double shielding, and LSZH jacket. Supports 600MHz bandwidth and stable 10Gbps transmission for data center and industrial network applications.
① Product Overview
The ITI-LINK ITI-CT7SF-020 CAT7 SFTP Shielded LAN Cable is a
professional-grade network cable designed for data center and
industrial network installations. Supplied in a 1000FT bulk length,
it supports large-scale structured cabling projects with high
performance and reliability.
② Performance
With support for up to 10Gbps Ethernet transmission and 600MHz
bandwidth, this CAT7 SFTP Cable ensures fast, stable, and
low-latency data transfer. The shielded LAN cable design
effectively minimizes electromagnetic interference (EMI) and
crosstalk.
③ Structure & Materials
The cable is constructed with 23AWG solid oxygen-free copper
conductors. Each twisted pair features individual foil shielding,
combined with an overall braided shield. The orange LSZH/PVC jacket
provides enhanced durability, fire safety, and easy identification.
④ Application Value
Designed as a professional Data Center Cable and Industrial Network
Cable, this CAT7 SFTP Shielded Ethernet Cable performs reliably in
high-interference environments and continuous data-load
applications.
⑤ Brand Trust
ITI-LINK delivers reliable networking solutions manufactured to
international standards, trusted by engineers and system
integrators worldwide.
Product Description: CAT7 SFTP LAN Cable 1000FT 23AWG Solid Copper LSZH 10Gbps Data Center & Industrial Cable | ||||||
| Rev.: A | ECN Description: | |||||
| Construction Item Description | Electrical Property | |||||
Conductor | Material | Bare Solid Copper(elongation: 19-24%) | Conductor Resistance at 20°C | ≤ 9.5 Ω / 100m | ||
| OD | 23 AWG | Resistance unbalance within a pair | ≤ 2% | |||
Insulation | Material | PE Skin-Foam-Skin | Insulation Resistance at 20°C after 2min of electrification under a DC voltage between 100 & 500V | >1500 MΩ / 100m | ||
| OD | 1.33 ±0.01 mm | Mutual capacitance | 5600 pF / 100m MAX | |||
| Average THK | 0.37mm | Capacitance unbalance pair to ground at 800Hz or 1 kHz | ≤ 160 pF / 100m | |||
Color | 1p: white + 2 blue stripes & blue | Characteristic impedance at 100MHz | 100 ± 15 Ω | |||
2p: white + 2 orange stripes & orange | Dielectric Strength Test Voltage (cd/cd,cd/screen): 1.00KV DC or 0.7 KV AC for 1 min | No breakdown | ||||
| 3p: white + 2 green stripes & green | Mechanical Property | |||||
| 4p: white + 2 brown stripes & brown | insulation | elongation before aging | ≥ 300% | |||
Pair Twist | Lay & Direction | 1p: S=19.0 mm (28%) | tensile strength before aging | ≥16 MPa | ||
| 2p: S=23.5 mm (31%) | elongation after aging | ≥ 150 % | ||||
| 3p: S=21.5 mm (33%) | tensile strength after aging | ≥10.5 MPa | ||||
| 4p: S=25.0 mm (36%) | jacket | elongation before aging | ≥ 125 % | |||
| OD | / | tensile strength before aging | ≥ 10 MPa | |||
Inner Assemble | Lay | S=90 ± 5 mm | elongation after aging | ≥ 100 % | ||
| Direction | according to the drawing | tensile strength after aging | ≥ 8 MPa | |||
| OD | / | Packing | ||||
Filler | Ripcord | 3*250D | Drum | NA | ||
| Drain Wire | / | |||||
Pair Shield | Shield | Pair Shield | ||||
| Construction | / | |||||
| Material | Polyester/Aluminium (PET/ALU) | |||||
| Coverage | ≥ 115% | |||||
Braid | Material | ɸ 0.12mm Aluminum-magnesium braided | ||||
| Coverage | ≥ 40% | |||||
Jacket | Material | LSZH, 60P, -20~75℃ | ||||
| Hardness | 81± 3 | |||||
| OD | 8.1 ± 0.2 | |||||
| Average THK | 0.55 ~ 0.65 | |||||
Color | orange | |||||
| Marking Color | black | |||||
| Marking | according to the customer's requirements | |||||
| Electrical Properties | ||
| Conductor Resistance at 20°C | NF EN 50289-1-2 / IEC 60189-1 | ≤ 9.5 Ω / 100m |
| Resistance unbalance within a pair | NF EN 50289-1-2/ IEC 60708 | ≤ 2% |
Dielectric Strength Test Voltage (cd/cd): 1.00KV DC or 0.7 KV AC for 1 min Test Voltage (cd/screen): 1.00KV DC or 0.7 KV AC for 1 min | NF EN 50289-1-3 / IEC 61196-1-105 | No breakdown |
| Insulation Resistance at 20°C after 2min of electrification under a DC voltage between 100 & 500V | NF EN 50289-1-4 / IEC 60885-1 | >1500 MΩ / 100m |
| Mutual capacitance | NF EN 50289-1-5 /IEC 60189-1 | 5600pF / 100m MAX |
| Capacitance unbalance pair to ground at 800Hz or 1 kHz | NF EN 50289-1-5 / IEC 60189-1 | ≤ 160 pF / 100m |
| Characteristic impedance at 100MHz | NF EN 50289-1-11/ IEC 61156-1 | 100 ± 15 Ω |
| Spark Test | UL444 | 2000 ± 250VOC |
|
