LCD Display Solar Inverter 6.2KVA 48V Solar Hybrid Inverter Pure Sine Wave On Off Grid Inverter with MPPT Solar Charger

Categories Solar Hybrid Inverter
Brand Name: SZSSTH
Model Number: VICTOR NM-ECO-6.2KW PLUS
Place of Origin: Guangdong, China
Price: CN¥1,814.20/pieces 1-499 pieces
Input Voltage: 48V
Output Voltage: 220V 230V
Output Current: Load
Output Frequency: 50Hz/60Hz
Output Type: Single
Size: 420*350*110mm
Type: DC/AC Inverters
Inverter Efficiency: 98%
Weight: 8.9kg
Product name: Hybrid Solar Inverter 6.2Kw
Inverter type: Hybrid Off Grid Solar Inverter
Controller type: MPPT Solar Controller
Communication: WiFi/GPRS(Optional)
Battery type: Lead Acid \ Lithium \ Gel
Protection: Overload
Rated power: 6200VA
AC Voltage: 230VAC
Display: LCD Display
Max PV voltage: 500V
Certificate: CE, ROHS
Warranty: 1 year
  • Haven't found right suppliers
  • Our buyer assistants can help you find the most suitable, 100% reliable suppliers from China.
  • And this service is free of charge.
  • we have buyer assistants who speak English, French, Spanish......and we are ready to help you anytime!
Submit Buying Request
  • Product Details
  • Company Profile

LCD Display Solar Inverter 6.2KVA 48V Solar Hybrid Inverter Pure Sine Wave On Off Grid Inverter with MPPT Solar Charger

Products Description
Product Image 1 Product Image 2
Product Features
  1. Pure sine wave solar inverter(on/off Grid)
  2. Output power factor 1.0
  3. WIF&GPRS available for lOS and Android
  4. Inverter can run without battery
  5. One-key restoration to factory Settings
  6. Built-in Lithium battery automatic activation
  7. Dual communication ports for Battery communicationand Wifi communication
  8. Built-in 140A(for 4.2KW)/120A(for 3.6KW16.2KW)MPPT Solar charge:max 6200W(for 3.6KW/4.2KW)max 6500W (for 6.2KW)
  9. High PV input voltage range(60~500VDC)
  10. Built-in anti-dust kit for harsh environment
  11. Smart battery charge design to optimize battery life
  12. Dual output
MODELVICTOR NM-ECO-3.6KWPLUSVICTOR NM-ECO-4.2KWPLUSVICTOR NM-ECO-6.2KWPLUS
Phase1-phase
Maximum PV Input Powe6200W6200W6500W
Rated Output Power3500W/3600VA4200W/4200VA6200W/6200VA
Maximum Solar Char gig Current120A140A120A
GRID-TIE OPERATION
PV INPUT(DC)
Nominal DC Voltage/Maximum DC Voltage360/500VDC
Start-up Voltage /Initial Feeding Voltage60VDC/90VDC
MPPT Voltage Range60-450VDC
Maximum Input Current1/18A1/22A
GRID OUTPUT(AC)
Nominal Output Voltage220/230240VAC
Output Voltage Range195.5-253VAC
Nominal Output Curren15.7A18.2A27.0A
Power Factor>0.99
EFFICIENCY
Maximum Conversion Efficiency (DC/AC)98%
TWO LOAD OUTPUT POWER
Full Load360DW42DDW6200W
Maxium Main Load350DW4200W6200W
Maxium Second Load(battery mode)1200W1400W2067W
Maxium Load Cut Off Voltage26VDC26VDC52VDC
Maxium Load Return Voltage27VDC27VDC54VDC
OFF-GRID OPERATION
AC INPUT
AC Start-up Voltage/Auto Restart Voltage120-140VAC/180VAC
Acceptable Input Volta ga Range90-280VACor 170-280VAC
Frequency Range49-51±1HZ
Maximum AC Input Current30A30A40A
PV INPUT(DC)
Nominal DC Voltage/Maximum DC Voltage360/500VDC
MPPT Voltage Range60-450VDC
Maximum Input Current1/18A1/22A
BATTERY MODE OUTPUT(AC)
Nominal Output Voltage220/230/240VAC
Oul put WaveformPure sine wave
Eficiency (DC to AC)94%
BATTERY&CHARGER
Nominal DC Voll age24VDC48VDC
Maximum Solar Charging Current120A140A120A
Maximum AC Charging Current100A100A100A
Maximum Solar+AC Charging Current120A140A120A
HYBRID OPERATION
PV INPUT(DC)
Nominal DC Voltage/Maximum DC Voltage360/500VDC
Start-up Voltage /initial Feeding Voltage90VDC/120VDC
MPPT Voltage Range60-450VDC
Maximum Input Curren1/18A1/22A
GRID OUTPUT(AC)
Nominal Output Voltage220(230/240VAC
Output Molt age Range195.5-253VAC
15.7A18.2A27.0A
AC INPUT
AC Start-up Voltage /Auto Restart Voltage120-140VAC/180VAC
Acceptable Input Voltage Range90-280VACor 170-280VAC
Maximum AC lnput Current30A30A40A
Maximum AC Charging Current100A
GENERAL
PHYSICAL
Dimension, D*W*H(mm)420*350*110
Cartoon Dimension, D“W*H(mm)500*416*180
Net Weight(kgs)888.9
Gross Weight(kgs]9910
INTER ACE
Communication PortRS 232/R 8485/WIFI/GPRS/LITHIUM BATTERY
ENVIRONMENT
Humidity5% to 95% Relative Humidity(Non~condensing)
Cpa rating Temperature
STANDARD
Compliance SafetyCE
