| Categories | LiFePO4 Cells Series |
|---|---|
| Brand Name: | Headway |
| Max Load Quantity(cells): | 288wh |
| Battery Type: | Solid state |
| Cycle Life: | 3000 cycles |
| Dimension (L*W*H): | 145*213*43mm |
| Application: | Toys, Power Tools, Home Appliances, Consumer Electronics, Golf Carts, SUBMARINES, Electric Bicycles/Scooters, electric vehicles, Electric Wheelchairs, Electric Power Systems, Solar Energy Storage Systems, Uninterruptible Power Supplies, Electric Forklifts |
| Model Number: | HW40175 |
| Weight: | 2kg, ~2000 g |
| Operating Temperature(℃): | -40 to 70 |
| Place of Origin: | China |
| Cathode Materials: | LiFePO4 |
| Nominal capacity: | 45 |
| Minimum capacity: | 42 |
| Max Charging voltage: | 6.4V |
| Discharge ending voltage: | 5.0V |
| Cell dimension: | 145*213*43mm(Excluding outgoing wiring harness) |
| Max. Continuous Charge Current: | 30A |
| Max. Continuous Discharge Current: | 30A |
| Anode Material: | LFP |
| Electric Energy: | 288Wh |
| Company Info. |
| Zhejiang Xinghai Energy Techology Co., Ltd. |
| Verified Supplier |
| View Contact Details |
| Product List |
Nominal capacity | 45Ah |
Minimum capacity | 42Ah |
Nominal voltage | 6.4V |
Energy | 288Wh |
Internal Resistance(ACR) | ≤30mΩ (without BMS) |
Charge current | 30A |
Cycle Life | ≥3000 cycles |
Design Lifet | ≥10 years @25℃ |
Self-Discharge (30 days) | ≤5% @25℃ |
Efficiency of Charge | ≥98% |
Charge Mode | 0.2C to 7.3V, then 7.3V charge current to 0.02C (CC/CV) |
Cell dimension | 145*213*43mm（Excluding outgoing wiring harness） |
Weight | ~2000 g |
Energy density | 144Wh/kg |
|
