| Categories | Electrical Insulation Board |
|---|---|
| Model Number: | 3250 |
| Place of Origin: | China |
| MOQ: | 1000kgs |
| Price: | basing on size and quantity |
| Payment Terms: | T/T |
| Supply Ability: | 200000kgs per month |
| Delivery Time: | 30 working days |
| Packaging Details: | pallet |
| Thickness: | 1mm / 2mm |
| Density: | 1.8-2.0 g/cm3 |
| Water absorption: | ≤ 0.5% |
| Tensile strength (MD): | ≥300MPa |
| Vertical electric strength: | ≥ 14.2 kV/mm |
| Parallel breakdown voltage: | ≥ 35kV |
| Dielectric dissipation (50Hz): | ≤ 0.04 |
| Relative Permittivity (50Hz): | ≤ 5.5 |
| Comparative tracking index: | ≥ 200 |
| Insulation resistance (after 24h immersion in water): | ≥ 5.0 × 10^4 MΩ |
