| Battery Voltage: | 12V |
| Rated Capacity: | 72Ah |
| Cycle Life: | >10000cycles @1C,80% DOD |
| Housing Protection: | IP65 |
| Charger and Discharge Temperature: | -40℃ to 85℃ |
| Communication: | Bluetooth |
| Continuous Discharge Current: | 150A |
| Pulse Discharge Current: | 300A (<30S) |
| Company Info. |
| HEFEI ECOLITE ENERGY CO., LTD. |
| Verified Supplier |
| View Contact Details |
| Product List |
The EcoLite ECOLTO12-72 (12V 72Ah) stands as the top-tier LTO
Battery Pack engineered for adaptability and longevity. Driven by
Lithium Titanate (LTO) chemistry—recognized globally as the most
secure lithium technology—this LTO Battery Pack delivers 864Wh of
steady energy, outperforming traditional lithium-ion and lead-acid
batteries in service life, climate adaptability, and power output.
Unlike cumbersome industrial LTO Battery Pack variants or
low-capacity consumer models, this unit hits a sweet spot: weighing
a mere 11kg for easy portability, while boasting enough strength to
handle medium-load demands. Every aspect of this LTO Battery Pack,
from its M8 heavy-duty terminals to Bluetooth-enabled tracking, is
crafted to solve real-world power hurdles, making it the preferred
choice for off-grid adventurers, industrial technicians, and
emergency preparedness teams.
Specifications
| Electrical Parameters | Mechanical Parameters | ||
| Battery Voltage | 12V | Dimension(WxDxH) | 260x168x209mm |
| Nominal Capacity | 72Ah | Dimension(WxDxH) | 10.24 x6.61x8.23 |
| Energy | 864Wh | Weight | 11kg |
| Resistance | ≤12mΩ | Terminal Type | M8 |
| Efficiency | ≥0.99 | Battery Housing | ABS |
| Cycle Life | >10000cycles @1C,80% DOD | Housing Protection | IP65 |
| Self Discharge | <2% per Month | Cell Type-Chemistry | LTO Cell |
| Cell in Series/Parallel | 5S/48P | Communication | Bluetooth |
| Discharge Parameters | Charge Parameters | ||
| Continuous Discharge Current | 150A | Charge Method | CC-CV |
| Pulse Discharge Current | 300A (<3S) | Charge Voltage | DC13.75V-DC14V |
| Recommended Volt. Disconnect | 7.5V | Recommended Float Voltage | DC13.5V-DC13.75V |
| BMS Discharge Cut-off Voltage | 7.5V | Recommended Charge Current | 72A |
| Reconnect Voltage | 10.5V | Maximum Charge Current | 150A |
| Short Circuit Protection | 100-200us | BMS Charge Cut-off Voltage | 14.25V |
| Temperature Parameters | |||
| Discharge Temperature | -40℃ to 85℃ | ||
| Charge Temperature | -40℃ to 85℃ | ||
| Storage Temperature | -10℃ to 35℃ | ||
| BMS High Temperature Cut-off | 90℃ | ||

This isn’t a standard lithium battery—it’s a purpose-engineered LTO Battery Pack that leverages LTO’s unique traits to overcome common pain points: climate restrictions, prolonged charging times, and frequent replacements. Here’s how this LTO Battery Pack distinguishes itself:
Decades-Long Lifespan: >10000 cycles (@1C, 80% DOD) – 20x longer than lead-acid and 5x
longer than standard lithium-ion batteries, cutting replacement
costs drastically and avoiding frequent downtime for this LTO
Battery Pack 1.
All-Climate Toughness: Charges and discharges reliably at -40℃~85℃
(BMS high-temperature cut-off at 90℃) – works in Arctic cold,
desert heat, or humid coastal areas, unlike climate-limited
batteries that stall in extremes 2.
150A Quick Charging: Reaches 80% capacity in 30 minutes (max 150A charge current) and 100% in 1.2 hours – 5x faster than lead-acid and 2x faster than slow-charging LTO Battery Pack alternatives, ideal for time-sensitive tasks .
Stable Medium-Load Power: 150A continuous discharge (runs winches, air compressors, or small
motors) and 300A pulse discharge (<1S, for quick
acceleration/tool activation) – maintains steady 12V output without
voltage drops, outperforming low-capacity batteries that falter
under load
Low Self-Discharge & Efficiency: <2% self-discharge per month
(vs. 5%+ for lithium-ion) and ≥99% efficiency – stays charged
during long storage (e.g., seasonal gear) and wastes less energy,
making this LTO Battery Pack more cost-effective long-term 4.
Rugged & Smart Design: IP65 dust/water resistance (ABS housing) for outdoor/industrial
use + Bluetooth real-time monitoring – track SOC, voltage, and
temperature via app (no manual checks) and resist damage from
splashes or debris .
Ideal Uses: Where This LTO Battery Pack Shines
The EcoLite ECOLTO12-72’s compact size, all-climate performance,
and power make it the perfect LTO Battery Pack for diverse
scenarios:
Outdoor Adventure Gear: Powers snowmobiles, ATVs, or camping equipment (portable fridges,
LED lights). Its lightweight design (11kg) and quick charging fit
adventure lifestyles, while -40℃ tolerance handles winter
trips—this LTO Battery Pack is essential for outdoor enthusiasts.
Portable Medical Gear: Supports devices like portable oxygen concentrators or mobile
ultrasound machines. The LTO Battery Pack’s stable power and wide
temperature range ensure reliability in clinics, field hospitals,
or emergency response situations.
Industrial Auxiliary Setups: Powers small pumps, sensors, or tools at construction sites or
remote industrial facilities. IP65 shielding resists dust and
water, while 150A discharge handles medium-duty loads—this LTO
Battery Pack keeps operations running smoothly.
Small Electric Vehicles (EVs): Acts as an auxiliary LTO Battery Pack for electric scooters, golf carts, or mini EVs. 300A pulse discharge handles acceleration, and quick charging reduces downtime between uses—ideal for recreational or utility EVs.
|
