| Categories | Wired |
|---|---|
| private mold: | Yes |
| products status: | Stock |
| type: | Portable Scanner |
| scan element type: | CMOS |
| colour depth: | 32 Bit |
| interface type: | usb, PS/2, rs232/485 |
| max paper size: | n/a |
| optical resolution: | 640X480 pixels |
| scan speed: | Up to 30fps |
| Brand Name: | winson |
| Place of Origin: | Guangdong, China |
| warranty(year): | 1-Year |
| after-sales service: | Call Center and on-line Technical Support |
| software development kit (sdk): | Yes |
| color: | Black |
| Voltage/Current: | DC 5V+-10%; Max 120ma |
| Sensor Resolution: | 648*480 pixels |
| Interface: | USB HID KEYBOARD / USB VCP |
| Photo Sensor: | CMOS array sensor |
| Aim Light Source: | White LED*1 |
| Min .Resolution: | 1D:5mil(0.127mm) 2D:13mil(0.33mm) |
| Min.PCS value: | >30%UPC/EAN 13(13mil) |
| Dimensions (L*W*H): | 67mm * 97mm * 165 mm |
| Company Info. |
| Guangzhou Winson Information Technology Co., Ltd. |
| Verified Supplier |
| View Contact Details |
| Product List |
Interface Supported | RS-232/USB HID KEYBOARD/USB VCP |
Input Voltage | DC 5V±10% |
Current | Max:135mA |
Image Sensor | CMOS Array Sensor |
Sensor Resolution | 648X488 Pixels |
Light Source | White LED |
Aim Light Source | Red Bar LED |
Scanning Angle | Pitch angle:±60°;Skew angle:±60°;Tilt angle:±60° |
Field of View | 34°(H),26°(V) |
Min Resolution | 0.127/5mil（PCS 0.9） |
Min .PCS value | 〉25%UPC/EAN 13（13mil） |
Language | Multiple Languages |
Data Edition | Support for custom data output |
Decode Capability | 1D：UPC/EAN,Code 128, Code 39, Code 93, Code 11, Matrix 2 of
5,Interleaved 2 of 5, Codabar, MSI，GS1 Databar 2D：QR, PDF417，Data Matrix |
Dimensions | 70mm*95mm*168mm(L*W*H) |
Weight | 132.4g |
Indicator | Beeper, LED |
Temperature | -20°∽65°C / -4°∽149°F(operation) /-30°∽70°C /-22°∽158°F(storage) |
Humidity | 5 - 90% (operation) ) 5 - 90% (storage) |
Ambient Light: | Up to 80,000 lx |
Shock Drop Test | 1.5m drop onto concrete surface |
|
