Chemical Etching Metal Encoder Discs from Prototype to Mass Production

Chemical Etching Metal Encoder Discs from Prototype to Mass Production

Encoder Discs Overview
Xinhaisen Technology specializes in manufacturing high-accuracy chemically etched encoder discs for optical and magnetic encoding systems. Our precision etching process produces code discs with exceptional dimensional stability and pattern accuracy for motion control applications across various industries.

Encoder Discs Features

• Ultra-High Resolution - Achieves up to 10,000 lines per revolution
• Material Expertise - Stainless steel, brass, aluminum, and specialty alloys
• Sub-Micron Accuracy - ±0.01mm pattern positioning tolerance
• Burr-Free Edges - Critical for consistent signal generation
• Custom Designs - Absolute/incremental patterns, custom geometries
• Fast Delivery - Prototypes in 7 days, volume production scaling

Encoder Discs Specifications

Encoder Discs Applications

• Optical Rotary Encoders: For servo motors, robotics, CNC machinery, and precision instrumentation.

• Magnetic Rotary Encoders: As patterned back-irons or magnetic pole discs.

• Industrial Automation: In drives, actuators, and closed-loop control systems.

• Medical Devices: In imaging equipment, surgical robots, and pumps.

• Aerospace & Defense: For guidance systems, actuators, and avionics.

• Consumer Electronics: In high-end printers, scanners, and cameras.

Our Advantages

• Precision Core Competency: Our expertise in microfabrication via etching delivers unparalleled accuracy and feature resolution for encoder discs, surpassing stamped alternatives.

• Speed & Flexibility: We offer unmatched rapidity from quote to delivery. Our process is ideal for urgent prototypes, design changes, and handling both low-volume and high-volume orders efficiently.

• Design for Manufacturing (DFM) Support: We collaborate early to optimize your design for etchability, performance, and cost-effectiveness.

• Proven Reputation: We are recognized by our clients for high precision, fast turnaround, and the ability to produce a diverse range of complex parts with consistent quality.

• Vertical Control: Integrated management from material sourcing to final QC ensures reliable supply, consistent quality, and competitive pricing.

FAQ

• Q1: What are the benefits of etched encoder discs over stamped or laser-cut discs?
  A: Etched discs are burr-free, stress-free, and perfectly flat, eliminating signal noise. They allow for more complex and finer geometries than stamping without tooling costs, and offer better edge quality and faster throughput for fine features compared to laser cutting.
• Q2: Can you produce discs with an absolute position pattern (e.g., Gray code or pseudorandom code)?
  A: Absolutely. Our digital process is ideal for producing complex, non-repetitive code patterns required for absolute encoders with high accuracy.
• Q3: What file format do you require for production artwork?
  A: We prefer vector-based formats like AutoCAD DXF or DWG. We can also work with Gerber files and provide expert DFM analysis on your design.
• Q4: Do you offer any treatments to improve optical contrast for optical encoders?
  A: Yes, we offer post-etch blackening processes (e.g., black oxide on stainless steel) to maximize opacity and contrast for clear signal generation.
• Q5: What is your typical lead time for prototype and production orders?
  A: Prototypes can often be delivered in 1-2 weeks. Our production process is highly streamlined for speed, and we are specifically equipped to manage large-volume orders efficiently without sacrificing quality.
