Industrial Hydraulic Freight Pallet Elevator Lift System For Warehouse Cargo

Categories Industrial Goods Lift
Brand Name: HAOXIANG BRAND
Model Number: DSL2-5
Certification: CS/ISO
Place of Origin: GUANGDONG,CHINA
MOQ: 1 unit
Price: USD1600- USD6800 / UNIT
Payment Terms: T/T
Supply Ability: 2000 units per year
Delivery Time: 7-15 working days
Packaging Details: Naked packaging
Load Capacity: 2000kg
Lifting Height: 5m
Platform Size: 2000×2000mm
Power Supply: AC 380V/50Hz
Lifting Speed: 6M/min
Warranty: 12 Months
Product Name: Hydraulic Guide Rail Lift
Country of Origin: China
Control Mode: Hydraulic
Rated Load: Up to 30 tons,Customizable
  • Haven't found right suppliers
  • Our buyer assistants can help you find the most suitable, 100% reliable suppliers from China.
  • And this service is free of charge.
  • we have buyer assistants who speak English, French, Spanish......and we are ready to help you anytime!
Submit Buying Request
  • Product Details
  • Company Profile

Industrial Hydraulic Freight Pallet Elevator Lift System For Warehouse Cargo

Industrial Hydraulic Freight Lift with Double Guide Rails, 5m Lifting Height, Customizable Platform Size and Load


This cargo lift is built with safety in mind. It includes an emergency stop switch, overload protection, and a safety interlock to prevent misoperation. Its hydraulic system is equipped with an explosion-proof valve that prevents sudden platform drops in case of pipeline rupture. The system uses high-quality hydraulic oil and a high-efficiency power pack, ensuring smooth, silent, and energy-saving operation.


Technical Parameter
Specifications, sizes and colors can be customized according to customer requirements
ModelRated load (kg)Lifting stroke (mm)Lowering height (mm)Table size (mm)Lifting timeMotor power (kw)
DSL1-3100030001002000×18006m/min3
DSL1-121000120001002500×20006m/min3
DSL2-4200040001502000×18006m/min4
DSL2-102000100002003000×35006m/min4
DSL3-5300050001503000×18006m/min5.5
DSL3-8300080001502000×17006m/min5.5
DSL4-5400050002503000×40006m/min7.5
DSL4-104000100001505000×30006m/min7.5
DSL5-6500060004005800×30006m/min11
DSL10-1510000150004007000×50006m/min18.5
DSL15-91500090008008000×40006m/min30
DSL15-1015000100008009000×45006m/min30
