All-in-One Digital Label Printing, Foiling and Die Cutting Machine

Categories Label Printing Machine
Brand Name: EcooGraphix
Model Number: ECOO ZBS 320
Certification: ISO9000, CE
Place of Origin: China
MOQ: 1 SET
Price: Negotiable
Payment Terms: T/T
Supply Ability: 500 Sets/Year
Delivery Time: 30 DAYS
Packaging Details: Standard Export Packing
Machine Type: Label Printing Machine
Model: Ecoo Label IQ-330
Max. roll diameter: 350mm
Max. media width: 330mm
Max. Unwinding Diameter: 600mm
Max. Rewinding Diameter: 600mm
  • Haven't found right suppliers
  • Our buyer assistants can help you find the most suitable, 100% reliable suppliers from China.
  • And this service is free of charge.
  • we have buyer assistants who speak English, French, Spanish......and we are ready to help you anytime!
Submit Buying Request
  • Product Details
  • Company Profile

All-in-One Digital Label Printing, Foiling and Die Cutting Machine

Product Description
All-in-One Digital Label Printing, Foiling & Die Cutting Machine
Product Description
  1. Integrated Versatility: One machine, infinite possibilities. The Ecoo Label IQ-330 combines printing, laminating, cutting, and slitting into a single device, simplifying your production line and enhancing overall efficiency.
  2. Excellent Printing Performance: Whether using white, varnish, or colored UV inks, the Ecoo Label IQ-330 delivers outstanding print quality on a wide range of media, helping your labels stand out on the shelf.
  3. High precision cutting: Featuring ball screws and independent servo motors, the machine achieves a cutting accuracy of ±0.1mm, ensuring flawless labels every time.
  4. Wide Range of Applications: From food packaging and cosmetic labels to electronic product identification and industrial data encoding, the Ecoo Label IQ-330 handles it all with ease.
Digital Label Printing Machine
ModelEcoo Label IQ-330
Max. roll diameter350mm
Max. media width330mm
Print headEP i3200-U1x4
Ink TypeUV ink
Ink colorCMYK+W+V
Ink bottle capacity1L
Print speed4pass:56m/h 6pass:40m/h 8pass:28m/h
File formatJPG/ PNG/ PDF
Cutting length10-350mm
Cutting width10-320mm
Repeat die-cutting accuracy0.1mm
Number of die-cutting heads2
Number of slitting knivesStandard 3 (optional according to requirements)
Power consumption4kW
Power supplyAC220-240V, 50-60hz
Weight2000KGS
Printer size2500mm*1800mm*1700mm
Laminating specificationWide 330mm
Gold foil standardHot foil stamping
Printing resolution720*1200 720*1800 720*2400
Max. Printing width330*320mm
Min. Printing width330*100mm
Max. Printing length10000mm
Min. Printing length0.5mm
Thickness of printing materialsLess than 300g
Technical data
DescriptionBrandQuantityOrigin
Printing roller
3setsChina
Anilox rollerAuclean/Laser1setChina
Unwind tension controllerMitsubishi1setJapan
Rewind tension controllerZXTEC1setChina
Main motorWannan1setchina
TransducerMitsubishi2setsJapan
Magnetic power brake/clutchNingxia3setsChina
Electromagnetic valveAirtac2 setTaiwan
InverterSchneider1setFrence
AC ContactorSchneider2pcsFrance
Time relayC-LIN1pcChina
Solid relayOmron6pcsJapan
Micro relayWeidmiiller2pcsGermany
Temperature ControllerYuyao6pcsChina
Air switchesfromSiemens8pcsGermany
Low-pressure wiringSchneiderAllFrance
All the bearingNSK/CHINA
JAPAN/CHINA
Digital All in One Label Printing and Foiling Die Cutting Machine
Digital All in One Label Printing and Foiling Die Cutting Machine Digital All in One Label Printing and Foiling Die Cutting Machine Digital All in One Label Printing and Foiling Die Cutting Machine Digital All in One Label Printing and Foiling Die Cutting Machine
