| Categories | Hokuyo Laser Sensor |
|---|---|
| Brand Name: | Hokuyo |
| Model Number: | BRC-G24T |
| Place of Origin: | Japan |
| MOQ: | 1 |
| Price: | Negotiate |
| Payment Terms: | T/T, L/C |
| Supply Ability: | 100PCS/MONTHS |
| Delivery Time: | Negotiate |
| Packaging Details: | Carton |
| Description: | Fa Optical Remote Control System 4 Points, Handy Type |
| condition: | new and original |
| Manufacturer: | Hokuyo |
| Product No: | BRC-G24T |
| Power source: | Alkaline cell(1.5V 4 pcs) |
| Light source: | Infrared LED |
| Transmission distance: | 10m |
| F number display: | LCD |
| Weight: | Approx. 120g |
| Company Info. |
| Xiamen ZhiCheng Automation Technology Co., Ltd |
| Verified Supplier |
| View Contact Details |
| Product List |
Overview
High Reliability And Resistance Against Disturbance Noise
● Handy transmitter and thin, compac t- sized receiver on the
machine side will meet to various demands of remote control system
with high reliable data transmission.
●Able to transmit signal to one specific receiver among others by
corresponding code(F number code) between transmitter and receiver.
This makes it possible to use several receivers in one trans-mitter
system.
Specifications
| Type | 4 points, handy type |
| Model No. | BRC-G24T |
| Power source | Alkaline cell(1.5V 4 pcs) |
| Light source | Infrared LED |
| Directional angle | 30°(Full angle) |
| Transmission distance | 10m |
| F number setting | Set by F number setting key |
| F number setting range | F-1 to F-9(9 points) or F001 to F225(255 points) (changeable with Mode Select Switch) |
| Fixing of F number | Available by F number fixing switch |
| F number display | LCD |
| Transmission method | Transmitted by transmission key(1 to 4) Double pressing is also available |
| Transmission check | Electronic buzzer(Ringing during transmitting) |
| Battery life display | LCD display(LOBAT, is display when lower) |
| Case | ABS resin(Handling part: Polyester film) |
| Weight | Approx. 120g |
