Electric UAV Multicopter Drone Platform Maximum 20kg Load Capacity

XH60E UAV Platform: 20kg Load Capacity, Vertical Take-off and Landing, Low Use Cost

The XH60E UAV platform is a large -length loading and long -time pure electric hexagonal drone system that has a universal mount capacity developed by our company. The platform can be equipped with a variety of load equipment, which can achieve air video data collection and real -time return, three -dimensional testing, emergency rescue, air throwing, air shouting, environmental monitoring and other tasks.
The drone system has the characteristics of stable performance, high reliability, high environmental applicability, high integration, simple use, etc., which can achieve full -time take -off and landing, cruise capabilities, dual redundant flight control systems, and multiple multiple. Safety control strategies ensure the safety and reliability of flight use.
The drone platform has the following characteristics and advantages:
a) Practical efficiency: It has a maximum load capacity of 20kg, which can be equipped with cameras, pods and other security, police, and inspection fields;
b) Vertical take -off and landing: small take -off and landing venues, strong environmental applicability;
c) Low use cost: The high -voltage lithium battery equipped with 500 charging life is standard, without additional use costs;
d) Simple operation: Integrate special flight control and navigation systems. The whole process is fully flying. The operator only needs to send a flight plan without professional training and operating experience;
e) Modular design: No complex auxiliary equipment is required, transportation, development, maintenance, and withdrawal are simple.
Table 1 technical parameter
Performance/indicator parameters
Number of rotor 6
Symmetric wheelbase 1800mm
Expanded size (excluding paddle leaves) 1917*1917*450mm (long*width*height)
Folding size 1100*1000*650mm (long*width*height)
Maximum take -off weight 60kg
Maximum effective load 20kg
Aircraft weight (excluding battery) 15kg
Power battery weight 23kg
Working frequency band 2.4GHz
Full load flight time 34min (500 meters above sea level)
Maximum climbing speed 6m/s
The maximum decrease speed is 5m/s
Maximum flat flying speed 17m/s
Maximum flight altitude 5000M
IP protection level ip45
Working environment temperature -20 ° C to 50 ° C
Maximum wind resistance 15m/s (level 7 wind)
The size of the transport box 1128*1129*690mm (length*width*height)
The size of the transport box 1104*1104*660mm (length*width*height)
Transportation weight (including aviation aviation box) 50kg
