RS485 Solar Charge Controller LCD Screen Solar Charge Regulator IP32

Categories Solar Charge Controller
Certification: ISO, CE
Model NO.: HT-SD20-10A
Application: Solar System Controller, Charger Controller, Lighting Controller, Wind Controller, Solar Working Station, Voltage Controller
Rated Voltage: 12V
Display Language: Bilingual: Chinese and English Switching
Display: Color LCD Screen + Touch Keys
Cooling Mode: Temperature-Controlled Fan Forced Air Cooling
Noise(dB): <30dB
Protection Grade: IP32 [Indoor]
Ambient Humidity: 0%~98% Without Condensation
Connecting: Tc Series Barrier Wiring Connection
Communication: Modbus RTU,RS485(Optional)
Night Standby Loss(W): <0.5W
Equal-Charging Duration: 120 Minutes
Transport Package: Wooden Box
Specification: 252x180x63mm
Trademark: htonetech
Origin: China
Supply Ability: 50000pieces/Year
Shipping Cost: To be negotiated| Freight Cost Calculator
After-sales Service: Yes
Warranty: 5year
Condition: New
  • Haven't found right suppliers
  • Our buyer assistants can help you find the most suitable, 100% reliable suppliers from China.
  • And this service is free of charge.
  • we have buyer assistants who speak English, French, Spanish......and we are ready to help you anytime!
Submit Buying Request
  • Product Details
  • Company Profile

RS485 Solar Charge Controller LCD Screen Solar Charge Regulator IP32

RS485 Solar Charge Controller LCD Screen Solar Charge Regulator IP32

Product Description

Solar charge controllers come with various features that enhance their functionality and efficiency within solar energy systems. Here are some common features found in solar charge controllers:

Maximum Power Point Tracking (MPPT): MPPT technology allows the charge controller to optimize the power output from the solar panels by continuously tracking and adjusting the operating point to ensure maximum power extraction. MPPT controllers are more efficient than PWM controllers, especially in systems with higher voltage solar panels.

  1. Multiple charging stages: Advanced charge controllers offer multiple charging stages, including bulk, absorption, and float stages. Each stage provides a different charging voltage and current profile, ensuring efficient and complete charging of the batteries.
  2. Battery type compatibility: Charge controllers are designed to be compatible with specific battery chemistries, such as lead-acid (including flooded, gel, and AGM) or lithium-ion. They have charging algorithms tailored to the specific charging requirements of the battery type, ensuring optimal charging and battery lifespan.
  3. Battery temperature compensation: Some charge controllers have temperature sensors to monitor the battery temperature. They adjust the charging voltage based on the temperature to compensate for temperature variations, ensuring accurate and efficient charging.
  4. Load control and timers: Charge controllers with load control functionality allow direct powering of DC loads such as lights or appliances. They can automatically turn on or off the connected loads based on the battery's state of charge or set schedules through timers.
  5. LCD display and monitoring: Many charge controllers come with built-in LCD displays that provide real-time monitoring of important system parameters, such as battery voltage, charging current, solar panel output, and load status. This allows users to easily monitor the system's performance and make informed decisions.
MPPT Solar Power Generator Controller System Charge Home Industry Power Energy with IndustryMPPT Solar Power Generator Controller System Charge Home Industry Power Energy with Industry
Product TypeHT-SDC48V-80AHT-SDC96V-120AHT-SDC120V-50AHT-SDC220V-50A
System specification
Rated Battery Voltage(Vdc)48V96V120V220V
Rated charge current(A)80A-150A50A-150A50A-150A50A-150A
Maximum solar panel in-put voltage(Vdc)100V<200V≤240V≤440V
Maximum solar panel in-put power (kW)3840W11.5KW6KW-18KW11KW-33KW
Solar panel in-put array111/2
Electrical Specification
three-phase charging modeFast charging, Euqal-charging, Float charging
Euqal-charging voltage(Vdc)57.6V115.2V144V264V
Fast charge recovery voltage(Vdc)52.8V105.6V132V242V
Floating charge voltage(Vdc)55.2V110.4V138V253V
Overcharge protection voltage(Vdc)64V120V160V293.3V
Overcharge recovery voltage(Vdc)60V117.6V150V275V
Equal-charging duration120 minutes
Night standby loss(W)<0.5W
Operating ambient temperature range (ºC)-25ºC~+55ºC
Ambient Humidity0%~98% without condensation
CommunicationMODBUS RTU,RS485(optional)
Hardware specification
ConnectingTC series barrier wiring connection
DisplayColor LCD screen + touch keys
Display languageBilingual: Chinese and English switching
Protection gradeIP32 [Indoor]
Cooling modeTemperature-controlled fan forced air cooling
Noise(dB)<30dB
Working altitude(m)3000m,More than 3000m need to be derated
InstallationWall-mounted
Dimension [width/depth/height]420*342*175mm
Net weight(kg)10KG
MPPT Solar Power Generator Controller System Charge Home Industry Power Energy with IndustryMPPT Solar Power Generator Controller System Charge Home Industry Power Energy with IndustryMPPT Solar Power Generator Controller System Charge Home Industry Power Energy with IndustryMPPT Solar Power Generator Controller System Charge Home Industry Power Energy with Industry

FAQ

1. Q: Are you a factory or a trading company?
A :We are a professional Solar Panels Manufacturer in China

2.How can we guarantee the products quality?
A :Always provide the esteemed buyer a pre-production sample before mass production; Always testing every product before despatching the shipments;

3.What products we can supply you?
A :Solar panels,inverter,controller,cable,support frame and other solar power systems

4. Q: Can the products pricing be cheaper?
A :Of course, you will be offered a a very good discount with large quantities.

5.. Q: Can print our company's logo on the pv panels?
A :Yes! And we accept the OEM&ODM orders.
