Name: Low Cost 010V Output High Accuracy Pressure Sensor for Industrial Applications
Brand: KACISE
Price: 35.00 USD

Home > Printing Machine >

Low Cost 0-10V Output High Accuracy Pressure Sensor for Industrial Applications

Categories	Fluid Level Meter
Place of Origin:	CHINA
Brand Name:	KACISE
Model Number:	GXPS series
Certification:	CE
Packaging Details:	each unit has individual box and all boxes are packed in standard packages or customers requests available
Supply Ability:	1000 Piece/Pieces per Week negotiable
Price:	$35.00 - $60.00/pieces
MOQ:	1PCS
Delivery Time:	5-8 work days
output:	Optional 0/1-5V 0-10V 4-20mA
Usage:	Pressure Sensor
Theory:	Resistance Sensor
Output:	Analog Sensor
Name:	pressure sensor 0-10v
Pressure range:	0~2bar ......60bar
Accuracy:	±1%F.S, ±2%F.S, ±2.5%F.S
Port:	Shanghai or other

Contact Now

Add to Cart

Company Info.

Xi'an Kacise Optronics Co.,Ltd.

Verified Supplier

Haven't found right suppliers
Our buyer assistants can help you find the most suitable, 100% reliable suppliers from China.
And this service is free of charge.
we have buyer assistants who speak English, French, Spanish......and we are ready to help you anytime!

Submit Buying Request

Low cost Pressure sensor 0-10v

1. Parameter

Spec.	Value
Pressure range	0~2bar ......60bar
Load pressure	2 times nominal value pressure (2X)
Rupture pressure	3times nominal value pressure (3X)
Accuracy	±1%F.S, ±2%F.S, ±2.5%F.S
Stability	Typical value 1%F.S, Max. value: 2%F.S
Operating temperature	-40°C~125°C
Compensation temperature	-10°C~80°C
Medium compatibility	All Caustic Medium Compatible with 1Cr18Ni9Ti
Electrical performance	3 wire system
Output signal	0~5V
Power supply	10~24Vdc
Load pressure	(U-10)/0.02(Ω)
Insulation	>100MΩ@50V
Electric strength	500V@60 second
Vibration/Impact	10g/5~2000Hz, axes X/Y/Z20g sine 11ms
Pressure durable	2×10⁶pressure circle @25°C
Electrical connection	Packard, DJ7032-2.3, water proof joint
Pressure port	M14×1.5, M12×1, G1/2,
Pressure type	G,
Certificate	CE
EMI/EMC	EMI: EN50081-1/-2; EMC: EN50082-2

2. Electrical connection mode & structure:

Output signal
Three wire	0.5~4.5V, 1~3V, 1~5V (dc)

3. Feature

4. Apllications

The sensor is desgined specially for space flight, petroleum, chemical, mining machinery Testing System, micropressure measurement, high-speed railway carriage usage.
The customer is spreading all over the world for shipbuilding ,special truck,chemical industry,
Help our customer cut the cost obviously.

Packaging & Shipping

low cost pressure sensor 0-10v
