20AWG Tinned Copper Composite Shield Flexible HD Imaging Medical Wiring Harness

20AWG tinned copper composite shield flexible HD Imaging medical wire harness

1. Product description

20AWG tinned copper composite shield flexible HD Imaging medical wire harness with good anti-interference performance and transmission speed, the product is composed of 20AWG tinned copper composite shielding wire and flexible insulating material, which is suitable for the connection and transmission of high-definition imaging medical equipment.With high speed data transmission ability and better anti-interference performance, can ensure the image is clear and stable. Its flexible structure is suitable for complex installation environments of medical equipment, while its high reliability and durability ensure long-term stable operation.

Feel free to contact with us, if you ever needed to consider your wire harness solution.

2. Product information

3. Picture of real products

4. Application area

I: Medical imaging equipment: such as X-ray machine, CT scanner, MRI, etc. These devices use high-definition imaging technology to obtain images of internal tissues and bones. The 20AWG tinned copper composite shielded flexible wiring harness can be used to transmit high-quality image signals while providing good anti-interference capability to ensure image clarity and accuracy.

II: Endoscopes and surgical instruments: Endoscopes are used to examine and diagnose the internal organs and tissues of patients. The 20AWG tinned copper composite shielded flexible wire harness can be used to transmit video signals and power, connect endoscopes and displays or image processing equipment. In addition, it can be used for the connection of surgical instruments, such as high-definition cameras and light sources.

III: Medical robots and automated devices: Medical robots and automated devices play an important role in surgery and disease treatment. These devices often require sophisticated power supply and signal transmission. The 20AWG tinned copper composite shielded flexible wiring harness can meet the needs of high-speed data transmission and stable power supply.

5. Feature

I: Hd imaging transmission: The harness is designed for HD imaging applications and is capable of transmitting high-quality image signals. It provides excellent signal transmission performance, ensuring image clarity, detail, and accuracy.

II: Composite shielding design: The wire harness adopts composite shielding design, using tinned copper wire braided shielding layer. This shielding structure can effectively suppress the interference of external interference signals, provide good anti-interference performance, and ensure the stability and accuracy of image transmission.

6. Main products

I: Wiring harness of industrial control equipment:

Power wiring harness, signal wiring harness, control wiring harness, data wiring harness, video wiring harness, motor wiring harness, debugging wiring harness, cabinet wiring harness.

II: Medical equipment wire harnesses:

Endoscope wire harness, infusion pump power cord, ECG lead wire, monitor cable, electric operating table wire harness, electric knife wire harness and mechanical arm wire harness.

III: New energy wire harnesses:

Charging harness, energy storage harness, electric vehicle harness, navigation harness, automotive harness, instrument panel harness, sensor harness, compress or harness.

Jiangsu Shineplus Precision Technology Co., Ltd. was established in 2021, located in Baipu, Rugao City, Nantong Town, 3000M² production

area. Specializing in the design and manufacture of cable components, designed to provide customers with a comprehensive wiring system.

The main product directions are: green energy, industrial automation equipment, medical physiotherapy Equipment and medical imaging

equipment, rail transit, communication facilities equipment wiring system and other fields.

In addition, Guangdong Xinfusheng Connection Technology Co., LTD., established in 2020, is located in Guangdong Hong Kong Industrial Park, Humen Town, Dongguan City, with a production area of 4500M² and 150 employees. Specializing in the design and manufacture of cable components, aiming to provide customers with comprehensive wiring system solutions, the main product directions are: mainly in the field of medical and health products, but also involving green energy, industrial automation, high precision equipment, communication connection and other fields.
