| Categories | High Low Temperature Sensor |
|---|---|
| Brand Name: | KJTDQ |
| Certification: | CE,RoHS |
| Place of Origin: | Jiangsu,China |
| MOQ: | 5pcs |
| Price: | $7.3-9.9/pc |
| Payment Terms: | L/C, D/A, D/P, T/T, Western Union, MoneyGram |
| Supply Ability: | 120000 pcs/ mouths |
| Delivery Time: | 3-5 work days |
| Packaging Details: | Carton package |
| Max. load current: | 120mA |
| Operating temperature: | -25~180℃ |
| Protection category: | IP67 |
| Material active face: | PTFE |
| Company Info. |
| View Contact Details |
| Product List |
| Mounting | Non-Flush |
| SN | 15mm |
| Power supply | 10-36V DC |
| Housing size | M30*68 |
| Thread size | M18*1*49 |
| Output | NPN/PNP NO/NC |
| Temperature drift | ≤±10% |
| Hysteresis | 1-20% |
| Repeat accuracy | ≤5% |
| Load current | ≤200mA |
| Residual voltage | ≤2.5V |
| Consumption current | ≤10mA |
| Protection circuit | surge, overload, short-circuit, reverse polarity |
| Indicator | Yellow LED |
| Ambient temp. | -25 ~ 180ºC |
| Ambient RH | 35-95% |
| Frequency | 500Hz |
| Protection degree | IP67 |
| Housing material | Nickel-copper Alloy |
| Connection | Cable 2m |
High temperature proximity sensors are mainly used in high temperature working areas, such as Casting workshop, Steel workshop, Barbecue workshop, Carbon fiber equipment, Food processing workshop, Galvanizing equipment, Glass manufacturing workshop, Stamping boiler, etc.
