Categories | Partial Discharge Test Equipment |
---|---|
Brand Name: | HNMC |
Model Number: | MCPDP001 |
Place of Origin: | China |
MOQ: | 1 |
Price: | Negotiable |
Supply Ability: | 50 sets per month |
Delivery Time: | 30-45 days |
Packaging Details: | Carton package |
Application: | GIS, Transformer, SG, etc |
Function: | PD test & location |
UHF Location: | -75dBm- 0dBm |
AE location: | 0dBuV-68dBuV |
Multifuction Partial Discharge Location System
Technical Parameter
UHF Location (2-8 channels)
Measurement range | -75dBm - 0dBm |
Sensitivity | >12mm |
Resolution | +/-0.5dB |
Frequency response | 300MHz-1500MHz |
Output impedance | 50Ω |
AE location (double channels)
Measurement range | 0dBuV~68dBuV(0.001mv~1.000mv) |
Sensor sensitivity | -65 dB (0 dB=1 volt/μbar Valid value SPL) |
Resolution | 1dB |
Accuracy | +/-1dB |
Frequency range | 0-200kHz |
Feature
1) Suitable for Parital discharge Test and location of GIS, Transformer, Switchgear, cables and etc
2) Also can be used for online partial discharge monitoring & location of GIS and Switchgear
3) Two test & location way: ultrasonic, UHF
4) Multiple Atlas like PRPD,PRPS,Flying and etc
5) Inbuilt typical interference & discharge Atlas
6) Can auto identify signal type
7) Accurate location and anti-interference
8) Provide temperature , humidity, air pressure monitoring value
![]() |
