| Categories | Reducer Gear Box |
|---|---|
| Brand Name: | YIZGEAR |
| Model Number: | GB22080804 |
| Place of Origin: | CHINA |
| MOQ: | 1 Set |
| Price: | $1000/ Set |
| Payment Terms: | L/C, T/T, Western Union, D/P |
| Supply Ability: | 150 Sets/Month |
| Delivery Time: | 55 Days |
| Packaging Details: | Plywood Crate |
| Material: | 20CrNiMoA |
| Profile Type: | Helical Gear |
| Weight: | 500 Kg |
| Type: | Second Stage |
| Color: | Gray |
| Gear Type: | Hard Surface |
| Company Info. |
| Henan Yizhi Machinery Co., Ltd |
| Verified Supplier |
| View Contact Details |
| Product List |
Considerations When Choosing a Speed Reducer
The considerations when choosing speed reducers include:
a) Torque of the Motor
b) Geometry of the Shaft Housing
c) Speed of Motor
d) Selection of Speed Reducer
e) Performance of the Motor
f) Backlash in the Gearbox
g) Mounting and Connection
| Products | Gear Box/ Gear Reducer |
| Custom Made | √ |
| Gear Profile Type | Double Helical Gear |
| Gear Teeth manufacturing | Gear Hobbing/ Gear Grinding |
| Gear Teeth Grinding | √ |
| Module (M) | Custom |
| Number of Teeth (Z) | Custom |
| Pressure Angle (α) | 20°/ 14.5° |
| Helix Angle (β) | Custom |
| Teeth Accuracy Grade | ISO 6-7 Grade |
| Heat Treatment | Carburizing/Cement Quenching/Nitriding |
| Surface Hardness | 58-62 HRC |
| STEEL CODE GRADES COMPARISON | |||||
| CHINA/GB | ISO | ГΟСТ | ASTM | JIS | DIN |
| 45 | C45E4 | 45 | 1045 | S45C | CK45 |
| 40Cr | 41Cr4 | 40X | 5140 | SCr440 | 41Cr4 |
| 20CrMo | 18CrMo4 | 20ХМ | 4118 | SCM22 | 25CrMo4 |
| 42CrMo | 42CrMo4 | 38XM | 4140 | SCM440 | 42CrMo4 |
| 20CrMnTi | 18XГT | SMK22 | |||
| 20Cr2Ni4 | 20X2H4A | ||||
| 20CrNiMo | 20CrNiMo2 | 20XHM | 8720 | SNCM220 | 21NiCrMo2 |
| 40CrNiMoA | 40XH2MA/ 40XHMA | 4340 | SNCM439 | 40NiCrMo6/ 36NiCrMo4 | |
| 20CrNi2Mo | 20NiCrMo7 | 20XH2MA | 4320 | SNCM420 | |
|
