| Brand Name: | Yuwei |
| Model Number: | YWLX |
| Certification: | CE/ISO |
| Place of Origin: | China |
| MOQ: | 1 |
| Price: | Negotiable |
| Payment Terms: | L/C, D/A, D/P, Western Union, T/T |
| Supply Ability: | 200 unit per month |
| Delivery Time: | 8 -10 work days |
| Packaging Details: | bubble wrap / wooden case |
| Name: | Cartridge Filter |
| Material: | Stainless Steel 304/316L |
| Flow Rate: | 0.5-150 m3/hour |
| Connection: | Flange |
| Open Method: | Manual |
| Cartridge NO: | 1-60 pcs |
| Housing Surface: | Mirror/Sand Blast |
| Work Pressure: | 0.6 Mpa |
| Precision: | 0.1-100 micron |
| Cartridge Length: | 10/20/30/40 |
Introduction
Filter element liquid filter is a new type of multifunctional filter, which consists of two parts: filter and filter element. It has been widely used in water, oil, paint and other liquid purification and solid-liquid separation in machinery, metallurgy, chemical industry, textile, printing and dyeing, electroplating, medicine, food and other industries
Features
Application

Petrochemical industry: filtration of all kinds of oil products, solvents, refinery gas,
natural gas, etc.
Chemical fiber industry: polymer filtration;
Pharmaceutical, electronics industry: sterile gas preparation, water filtration.
Specification
| Model | Flow in theory(T/H) | The housing diameter(mm) | Height (mm) | Inlet/Outlet (DN) | Model | Flow in theory(T/H) | The housing diameter(mm) |
| YWLX10-1 | 0.1-0.3 | 102 | 500 | 25-32 | YWLX10-1 | 0.1-0.3 | 102 |
| YWLX20-1 | 0.3-0.5 | 102 | 750 | 25-32 | YWLX20-1 | 0.3-0.5 | 102 |
| YWLX30-1 | 1.2 | 102 | 1000 | 25-32 | YWLX30-1 | 1.2 | 102 |
| YWLX40-1 | 1.5 | 102 | 1250 | 25-32 | YWLX40-1 | 1.5 | 102 |
| YWLX10-3 | 1.2 | 160 | 650 | 25-40 | YWLX10-3 | 1.2 | 160 |
| YWLX20-3 | 1.5 | 160 | 900 | 25-40 | YWLX20-3 | 1.5 | 160 |
| YWLX30-3 | 3.6 | 160 | 1150 | 25-40 | YWLX30-3 | 3.6 | 160 |
| YWLX40-3 | 4.5 | 160 | 1400 | 25-40 | YWLX40-3 | 4.5 | 160 |
| YWLX20-5 | 2.5 | 200 | 900 | 25-50 | YWLX20-5 | 2.5 | 200 |
| YWLX30-5 | 6 | 200 | 1150 | 25-50 | YWLX30-5 | 6 | 200 |
| YWLX40-5 | 7.5 | 200 | 1400 | 25-50 | YWLX40-5 | 7.5 | 200 |
| YWLX20-7 | 3.5 | 230 | 900 | 25-50 | YWLX20-7 | 3.5 | 230 |
| YWLX30-7 | 8.4 | 230 | 1150 | 25-50 | YWLX30-7 | 8.4 | 230 |
| YWLX40-7 | 10.5 | 230 | 1400 | 25-50 | YWLX40-7 | 10.5 | 230 |
| YWLX20-9 | 4.5 | 300 | 900 | 25-50 | YWLX20-9 | 4.5 | 300 |
|
