Sleeve type soft sealing Lubricated Plug Valve ACC / ASME B16.34 Class 600 Lbs

Detailed Product Description

Name:	Plug Valve	Medium:	Acid, Alkali
Size:	DN15~DN400, 1/2"~16"	Pressure:	PN10~PN420, CLASS150~2500
Standard:	DIN/BS/AWWA/JIS	Temperature:	-20~120 C
Body:	ASTM A995 5A	Plug:	ASTM A-995 5A
Seat:	PTFE
High Light:	flanged plug valve , gas plug valve

Plug Valve On/Off sevice by Non Lubricated As ACC/ASME B16.34 Class 600 Lbs

Plug Valve On/Off sevice by Non Lubricated As ACC/ASME B16.34 Class 600 Lbs,

design pressure 100 bar to 20 Celuis

body hidrostatic test pressure Acc/API -598

seat close hidrostatic test pressre Acc/Api-598

Conform to API 6D, API 599, and ASME B16.34. They are tested according to API 598, and marked as per MSS SP-25

Construction is as follows:

- Regular Port
- Short, Regular or Venturi Pattern
- Bolted Bonnet with spiral-would gasket
- Anti-static Design & Blow-out proof stem
- Socket Weld Ends to ASME B16.11
- Butt Weld Ends to ASME B16.25
- Screwed Ends to ANSI/ASME B1.20.1
- Flanged Ends to ASME B16.5

Main Part & Materials

Part Names	Part Materials
Body	WCB/A105	LCB/LF2	WC6/F22	CF8/F304	CF8M/F316	CF3/F304L	CF3M/F316L
Bonnet	WCB/A105	LCB/LF2	WC6/F22	CF8/F304	CF8M/F316	CF3/F304L	CF3M/F316L
Plug	A105+ENP	SS304	F22	SS304	SS316	SS304L	SS316L
Seat/Seat Ring	PTFE or METAL
Packing	Graphite/PTFE
Gasket	SS304+Graphite/SS304+Graphite
Bolts/Nuts	B7/2H	L7/4	B16/4	B8/8	B8M/8M	B8/8	B8M/8M
Suitable Medium	W.O.G etc.			HNO3, CH3OOH etc.
Suitable Temperature	-29~425 °C	-46~340 °C	-46~340 °C	-196~427 °C	-196~427 °C	-196~427 °C	-196~427 °C

OUR ADVANTAGE

Normal Pressure Rating
PN10~PN420, CLASS150~2500

Normal Size Range
DN15~DN400, 1/2"~16"

Sleeve type soft sealing plug (DIN) is applicable to the cutting and connection of pipelines medium that are used in various industries such as petroleum, chemical industry, pharmacy, chemical fertilizer, power industry etc under nominal pressure of PN1.6~16Mpa, and working temperature of -29~180℃.

Description:

Main parts & materials:

Sleeve type soft sealing Lubricated Plug Valve ACC / ASME B16.34 Class 600 Lbs 0

No.	Part name	material
1	Body	GS-C25 1.7363 1.4308,1.4408,1.4306,1.4301
2	Sleeve	PTFE
3	Plug	ASTM A182-Gr,F6a,ASTM A182-F22 ASTM A182-F304,F316,F321,F304L,F316L
4	Gasket	Flexible graphite + stainless steel, PTFE
5	Adjusting gasket	ASTM A182-Gr,F6a,ASTM A182-F22 ASTM A182-F304,F316,F321,F304L,F316L
6	Cover	GS-C25 1.7363 1.4308,1.4408,1.4306,1.4301
7	Adjusting bolt	ASTM A193-B7, A320-B8, A193-B8M
8	Net	ASTM A194-2H, A194-8, A194-8M
9	Bolt	ASTM A193-B7, A320-B8, A193-B8M
10	Yoke	Q235,WCB
11	Worm

Feature:

1. The product has reasonable structure, reliable sealing, excellent performance and beautiful

appearance.

2. Its sealing is realized by the sealing face around the sleeve. It has unique 360 degree metal

edge for protection and fixing of the sleeve.

3. There Is no cavity in the valve for accumulation of medium.

4. Metal edge provides the function of self-cleaning when the plug is rotated,

applicable to the operation condition that is glutinous and apt to smudge.

5. Its characteristic double-direction flow makes installation and sue more convenient.

6. The materials of the parts and sizes of flanges can be reasonably configured according

the actual operation condition of the requirements of the customers, so as to meet

the various needs of engineering.

Executive standard

Structural formation	BC
Driving manner	worm & worm gear, pneumatic, electric-actuated ,Wrench wheel
Design standard	DIN
Face to face	DIN 3202F1
Flange end	DIN 2543-2549
Test & inspection	DIN 3230

The size of serial valve connecting flange can be designed according to customers requirement.

Nominal pressure(MPa)	Shell test(MPa)	Sealing test(MPa)	Suitable temp	Suitable medium
1.6	2.4	1.76	-29~180℃	Water, oil & gas
2.5	3.75	2.75
4.0	6.0	4.40
6.4	9.6	7.04
10.0	15.0	11.0
16.0	24.0	17.6

Main technical data

Sleeve type soft sealing Lubricated Plug Valve ACC / ASME B16.34 Class 600 Lbs 2

Main external and connection dimension

		KQDX43-16
pressure		PN16
size	mm	15	20	25	32	40	50	65	80	100	125	150	200	250	300	350
L		130	150	160	180	200	230	290	310	350	400	480	600	730	850	980
H		150	155	160	180	190	200	220	230	380	460	520	580	620	680	740
W		300	300	300	350	400	500	500	550	300	300	320	320	350	380	380
Weight		9	10	11	13	14	19	23	27	43	62	75	155	222	390	580
		KQDX43-25
pressure		PN25
size	mm	15	20	25	32	40	50	65	80	100	125	150	200	250	300	350
L		130	150	160	180	200	230	290	310	350	400	480	600	730	850	980
H		150	155	160	180	190	200	220	230	380	460	520	580	620	680	740
W		300	300	300	350	400	500	500	550	300	300	320	320	350	380	380
Weight		10	11	13	15	17	22	31	55	77	88	190	190	235	399	630
		KQDX43-40
pressure		PN40
size	mm	15	20	25	32	40	50	65	80	100	125	150	200	250	300	350
L		130	150	160	180	200	230	290	310	350	400	480	600	730	850	980
H		190	195	225	260	280	310	340	395	435	470	535	590	630	680	720
W		120	140	140	180	200	220	260	280	300	340	400	450	450	500	500
Weight		12	14	18	21	24	29	33	39	75	103	146	251	337	521	720
		KQDX43-64
pressure		PN64
size	mm	15	20	25	32	40	50	65	80	100	125	150	200	250	300	350
L		130	150	160	180	200	230	290	310	350	400	480	600	730	850	980
H		190	195	225	260	280	310	340	395	435	470	535	590	630	680	720
W		120	140	140	180	200	220	260	280	300	340	400	450	450	500	500
Weight		14	17	22	25	29	34	43	50	94	123	170	291	430	625	875
note: 100mm or above with worm gear
