I. the installation instructions

In order to save your precious time, this manual does not introduce common sense of common

use of electrical appliances,

please follow the common sense of common electrical appliances.Before using the device,

please read the operating instructions carefully so that you can quickly become familiar

with the commissioning and use of the device.

II. the installation steps

1. Connect the HDMI output of the splicing processor to the HDMI input port of the liquid crystal display unit,

and each display unit can be connected to any HDMI output port of the splicing processor;

2. Connect the signal source to be displayed to any one of the HDMI1, HDMI2, and DP interfaces;

3. The first time you set up the video wall controller, you need to connect to the RS232 interface of

the video wall controller through the serial cable.

The installation diagram is as follows:

III. power on

After the above cables are connected, plug in the 100-240V AC power supply,

turn on the power switch of the device,

the power indicator light is red, and the device is in working state;
