2 Electrodes 2R-5 Gas Discharge Tubes 1000-5000V 1pF Surge Protector 2KA 3KA 5KA Ceramic GDT

2 Electrodes 2R-5 Gas Discharge Tubes 1000-5000V 1pF Surge Protector 2KA 3KA 5KA Ceramic GDT

Description of 2R-5 Gas Discharge Tubes

2R-5 Gas Discharge Tubes (GDT) series provides high levels of protection against fast rising transients caused by lightning disturbances. Offered in a miniature surface mount package, it has a surge rating of 5KA/3KA/2kA 8/20μs.

2R-5 GDTs are high voltage (1000-5000V) components designed for surge protection and high isolation applications. It is also suitable for applications for which bias voltage or signal levels of several hundred volts are normally present. 2R-5 GDTs can be used in conjunction with MOVs (Metal Oxide Varistors) to provide superior protection performance for AC applications.

Features of 2R-5 1000-5000V Gas Discharge Tubes

• Voltage Ranges 1000V to 5000V
• Excellent response to fast rising transients
• 8/20μs Impulse current capability: 5KA/3KA/2kA
• Non-Radioactive
• Ultra Low capacitance (<1pF)
• Lead-free compliant
• RoHS and REACH compliant
• UL 1449 Recognized: E479668
• Size: Ф5.5mm*6mm
• Storage and operational temperature: -40~+125°C

Applications of 2KA 3KA 5KA Ceramic GDT

Automotive:
• On-board chargers
• Vehicle charging stations

Others:
• LED lighting
• Power supply
• Photovoltaic
• Air conditioning

Electrical Characteristics of 2KA 3KA 5KA Gas Discharge Tubes

Soldering Parameters - Reflow Soldering (Surface Mount Devices)

Reflow Condition

Pb - Free assembly

Pre Heat

-Temperature Min (Ts(min))

150°C

-Temperature Max (Ts(max))

200°C

- Time (min to max) (ts)

60 -180 Seconds

Average ramp up rate ( Liquids Temp TL) to peak

3°C/second max

TS(max) to TL - Ramp-up Rate

5°C/second max

Reflow

- Temperature (TL) (Liquids)

217°C

- Time (min to max) (ts)

60 -150 Seconds

Peak Temperature (TP)

260 +0/-5°C

Time within 5°C of actual peak Temperature (tp)

10 - 30 Seconds

Ramp-down Rate

6°C/second max

Time 25°C to peak Temperature (TP)

8 minutes Max

Do not exceed

260°C
