AAWG DWDM 1550nm FTTH Filter WDM Multiplexer C28 High Isolation

Categories Filter WDM
Brand Name: GEZHI or OEM
Model Number: HISOFWDM
Certification: CE RoHS,ISO9001
Place of Origin: China
MOQ: 1pc
Price: Negotiable
Payment Terms: T/T, Western Union
Supply Ability: 100000Channel per month
Delivery Time: 5-8 work days
Packaging Details: Paper box
Product Name: High Isolation Optical WDM multiplexer
Wavelength: 1310&1490&1550nm
Isolation: >30dB
Package: ABS 100x80x10mm
Connector: SC/APC
Application: FTTH
  • Haven't found right suppliers
  • Our buyer assistants can help you find the most suitable, 100% reliable suppliers from China.
  • And this service is free of charge.
  • we have buyer assistants who speak English, French, Spanish......and we are ready to help you anytime!
Submit Buying Request
  • Product Details
  • Company Profile

AAWG DWDM 1550nm FTTH Filter WDM Multiplexer C28 High Isolation


High Isolation Optical WDM multiplexer in optical fiber communication


GEZHI Photonics Co.,Ltd is a high-tech enterprise dedicated to R&D and manufacturing of optical fiber communication products. Our mainly products is DWDM, AAWG DWDM, FWDM, CWDM, and Optical Switches with all kinds of type.


GEZHI are serves the fields of telecommunications optical transmission network, optical access network, enterprise network, storage area network, data center and cloud computing system, and is a professional manufacturer of passive optical network devices.


Features

Applications

  • High Isolation
  • HIgh Reliability and channel isolation
  • Low Insertion loss
  • Wide Bandwidth
  • CATV
  • Telecommunication Network System
  • Fiber Optic Instruments
  • WDM system
  • Fiber Lasers

Specification

Type3port FWDM
Operating Wavelengthnm1310, 1490, 1550
Passbandnm±7.5
Channel Spacingnm20
1310nm Port ILdB<0.8
1490nm Port ILdB<1.0
1550nm Port ILdB<1.2
Isolation (Adjacent Channel)dB≥30
Isolation (Non-Adjacent Channel)dB≥40
PDLdB

≤0.1

Wavelength thermal stabilitynm/℃≤0.003
Insertion loss thermal stabilitydB/℃≤0.005
DirectivitydB≥55
Return lossdB≥45
Operating temperature

-20~+70


Storage temperature-40~+85
Fiber Typemm900um
Fiber Length/0.5m with SC/APC
Package Sizemm100x80x10

CWDMNumber of ChannelsConfigurationModule typeCable typeFiber lengthconnector
CWDM03=3 Channel
M=Mux
D=Demux
A=Mux+Demux
A1=ABS box 100x80x10mm
A2=ABS box 120x80x18mm
A3=ABS box 140x115x15mm
L1=LGX 129*29*130mm
09=900um loose tube
20=2.0mm
30=3.0mm

05=0.5m
10=1.0m
15=1.5m

20=2.0m
X=Customized

00=none
LP=LC/UPC
LA=LC/APC
SP=SC/UPC
SA=SC/APC
FP=FC/UPC
FA=FC/APC
X=Customized

Gezhi is a factory of fiber optical passive product located in Shenzhen, China. We comply with ISO9001 standard and all our product comply with RoHS. We produce Optical Switch, WDM, AWG product with stable performance and competetive price.
Optical Switch: 1x1, 1x2, 2x2Bypass, 2x2Full, 1x4, 1x8, 1XN all series optical switches.
WDM: CWDM, DWDM, FWDM, AWG all series WDM product.
