Brand Name: | Bonafe |
Place of Origin: | China |
MOQ: | 1 Units |
Payment Terms: | L/C, T/T, Western Union |
Supply Ability: | 5000 Unit/Units per Year |
Delivery Time: | 5-8 work days |
Product Category:: | Forklift Drum Clamp |
Material:: | Steel |
Applicable Industries:: | Widely used in the petroleum and chemical industry |
Weight:: | 613kg |
CGV:: | 335mm |
Opening Range:: | 460-1690mm |
Horizontal Center of Gravity:: | 277mm |
Effective Thickness:: | 239mm |
Company Info. |
Bonafe Technology Co., Ltd |
View Contact Details |
Product List |
4-Drum Revolving Drum Clamps For Forklift With Different Lift Capacity
Functions & Applications
Widely used in bulk cargo handling and piling work, such as oil, petrochemical, food and other industries.
Features
* Proven durable T-beam arm aluminum frame construction.
* Excellent driver visibility.
* Rubber pads on clamp arms can be replaced conveniently. It is economic and practical
Options
* Various mounting classes available
* Custom opening ranges
Parameter
Capacity@ Load Center (Kg@mm) | Model No. | Opening Range O (mm) | Frame Width C (mm) | Overall Height D (mm) | Hook Spread E (mm) | Vertical Center of Gravity CGV (mm) | Weight (kg) | Effective Thickness ET(mm) | Horizontal Center of Gravity CGH(mm) |
4-Drum Revolving | |||||||||
1900@500 | DFR20D-008A | 460-1690 | 940 | 775 | 815 | 335 | 613 | 239 | 277 |
Other size available on request.
Installation & Option
Hydraulic Flow & Pressure
Model | Min. Hydraulic Flow(L/min) | Rec. Hydraulic Flow(L/min) | Max. Hydraulic Flow(L/min) | Min. Hydraulic Pressure(Bar) | Max. Hydraulic Pressure(Bar) |
DTR20D | 20 | 40 | 60 | 35 | 160 |
DTR30D | 20 | 40 | 60 | 35 | 160 |
Rotator Specifications
Model | Rotator Speed | Rotator Torque |
DTR20D | 5.2r/min@57L/min | 9000N.m@160Bar |
DTR30D | 5.2r/min@57L/min | 9000N.m@160Bar |
Options:
* Heightening and large clamp arm.
* Left and right clip arm independent movement type.
Applicable Industries
Widely used in the petroleum and chemical industry and in other applications that require the handling of standard drums.
Can be customized according to size
Customized solutions:
Carton Clamp
Block Clamp
Bale Clamp
Roll Clamp
......
all kinds of attachment
![]() |
