Passive Dwdm Fiber Optic Mux Demux Module 200ghz Multiplexer And Demultiplexer

Passive Dwdm Fiber Optic Mux Demux Module 200ghz Multiplexer And Demultiplexer

Passive Dwdm Fiber Optic Mux Demux Module 200ghz Multiplexer And Demultiplexer
Passive Dwdm Fiber Optic Mux Demux Module 200ghz Multiplexer And Demultiplexer
Categories Fiber Optic Mux Demux
Brand Name: Sourcelight or OEM
Model Number: 200ghz Module
Certification: ISO9000 SGS CE FCC
Place of Origin: Shenzhen,China
MOQ: 1pcs
Price: Get Latest Price
Payment Terms: L/C, D/A, D/P, T/T, Western Union
Supply Ability: 1000pcs/Month
Delivery Time: Shipped in 3~5 days after PO confirmed
Packaging Details: 1pcs in a foam with paper box
Product Name: 200Ghz DWDM
Channel Number: 8 Channels
Wavelength: ITU Grid
Fiber Type: smf G652
Connector: LC/SC/FC/ST
Application:: Fiber Channel
Contact Now
Company Info.
Sourcelight Technology Limited
View Contact Details
Product List
  • Haven't found right suppliers
  • Our buyer assistants can help you find the most suitable, 100% reliable suppliers from China.
  • And this service is free of charge.
  • we have buyer assistants who speak English, French, Spanish......and we are ready to help you anytime!
Submit Buying Request
  • Product Details
  • Company Profile

Passive Dwdm Fiber Optic Mux Demux Module 200ghz Multiplexer And Demultiplexer

Passive Dwdm Fiber Optic Mux Demux Module 200ghz Multiplexer And Demultiplexer


Description

DWDM MUX DEMUX Modules with 50GHz/100GHz/200GHz channel spacing can be used to combine or separate wavelength channels at standard ITU grid. We supply the common configuration including 2, 4, 8, 16, 24, 32, 40, 44, and 48 channels.
These DWDM modules passively multiplex the optical signal outputs from 4 or more electronic devices, and send them over a single optical fiber and then de-multiplex the signals into separate, distinct signals for input into electronic devices at the other end of the fiber optic link.
Our standard package types of DWDM MUX DEMUX are Field Module ABS Plastic Box, 19" Rack Mount Chassis and LGX Metal Cassette Box. We also supply custom package to meet customers' requirements. All the DWDM MUX DEMUX modules provide excellent optical performance and high reliability to ease of fiber handling and power saving solution Duplex DWDM MUX & DEMUX

Technical Specs for 200GHz DWDM

ParameterUnitValue
Channels Number-2481620
Channel Central WavelengthnmITU-T Grid
Passband at 0.5dBnm≥0.6
Pass bandnmλITU±0.25
Pass band FlatnessdB≤0.5
Insertion Loss (Typ.)dB1.22.04.29.016.8
Insertion Loss (Max.)dB1.42.65.09.819.4
Adjacent Channel IsolationdB≥25
Non-adjacent Channel IsolationdB≥40
Return LossdB≥45
Polarization Mode Dispersionps≤0.10≤0.10≤0.10≤0.15≤0.15
Polarization Dependent LossdB≤0.10≤0.15≤0.20≤0.25≤0.25
DirectivitydB≥50
Operation Temperature°C-5~+70
Storage Temperature°C-40~+85
Package Dimensionmm

ABS box G: 100X80X10, H: 125X96X16

I: 141X115X18, O: customized

Multiplexer (MUX) and demultiplexer (DEMUX) are combined together into a single piece of equipment for bi-directional data transmission over two fibers.
Fs Three-types-transmission-way-for-Fiberstore-DWDM-MUX-DEMUX-Duplex-BIDI.jpg
