250V 10A DL142V-XX-5.08 PCB Spring terminal block 5.08mm

Categories PCB Connector
Brand Name: DELI
Model Number: DL142V-XX-5.08
Place of Origin: CN
MOQ: 100
Payment Terms: T/T, Western Union
Supply Ability: 10000
Delivery Time: 2DAYS
Packaging Details: BAG
Pitch: 5.08MM
Poles: 1P-xxP
Pin header: phosphor bronze 、Tin plated
Housing: PA66. UL94V-0
Rated voltage: 300V/250V
Rated current: 10A/15A
Withstanding voltage: AC2000V/1Min
Wire range: 24-14AWG
  • Haven't found right suppliers
  • Our buyer assistants can help you find the most suitable, 100% reliable suppliers from China.
  • And this service is free of charge.
  • we have buyer assistants who speak English, French, Spanish......and we are ready to help you anytime!
Submit Buying Request
  • Product Details
  • Company Profile

250V 10A DL142V-XX-5.08 PCB Spring terminal block 5.08mm

MATERIAL
Pitch:5.08MM
Poles: 1P-xxP
Pin header:phosphor bronze , Tin plate
Wire guard:Stainless Steel
Housing:PA66. UL94V-0
ELECTRICAL
Rated voltage:300V/250V
Rated current:10A/15A
Withstanding voltage:AC2000V/1Min
Wire range:24-14AWG
MECHANICAL
Temperature range:-40℃-- +105℃
MAX soldering:+250℃ for 5 sec
Strip length:11mm
DeLi Electronics Technology Co., Ltd
PART# :DL142V-XX-5.08
