Blue or Customer Requied Desulfurization Butterfly Valve With Handle Operated

Introduction:

Desulfurization butterfly vavle for my company is based on the current domestic flue gas desulfurization system and the design of products. To meet the limestone and gypsum slurry of corrosion, disc and dtem the use of a special corrsion-resistant alloys, vavle seats using high wear-resistant rubber, to a large number of liquidparticles in the erosion of the valve seats. Therefore products with high anti-corrosion and abradion resistance and high. Ad products are designed for user requirements, targeted and high reliability.

Medium to apply gypsum ash, sulfur dioxide, lime slurry paste, process water, and other aggressive media.

The disc of the wafer type butterfly valve is installed in the diameter direction of the pipe. In the cylindrical passage of the butterfly valve body, the disc-shaped disc rotates around the axis, and the rotation angle is between 0°-90°, which can play the role of flow regulation. When the disc rotates to 90°, the valve reaches the maximum. Opening degree.

The clip-on butterfly valve is simple in structure, small in size and light in weight, and consists of only a few parts. Moreover, it can be quickly opened and closed by only rotating 90°, and the operation is simple, and the valve has good fluid control characteristics.

性能规范 Technical data

主要零部件材料Meterial of main parts

Parameter:

主要尺寸表和重量Main dimensions and weight

注 Note:

DN50 ( 2")〜800 ( 32") “ A”型蝶阀分别适用于PN1.0/PN1.6MPa二种压力级,表中每格有两个尺寸的分别表示 PN1.0/PN1.6MPa二种压力级连接尺寸,与阀门连接的管法兰连接尺寸参照法兰连接尺寸表(图一).堞阀上法兰可通用于手动,蜗 轮蜗杆传动,电动,气动等.

表中DN50 (2”)〜500 (20”)中D1和n-(J>尺寸为堞阀本身安装定位尺寸,其中DN50(2"卜350(14")的D1和n-4>尺寸包容GB9112- 88,D丨N2501(德国),BS4504(英国),丨SO2084, IS02531(国际标准),BS10-E(英国),ANS11259(美国)等法兰连接标准. DN400(16"h500(20")包容GB9112-88,D1N2501,丨SO2084, BS4504法兰连接标准.

The dimensions D1 and n-Ф of DN50(2")-500(20") listed in above table show the installation dimensions of butterfly valve. Of them the dimensions D1 and n-4) of DN50(2">-350(14")contain the standard of GB9112-88, DIN2501(Germeny), BS4504(UK) ISO2084, IS02531(Internationa 1 standard) BS 10-E (UK) ANSI 125 (USA) for flange connection and DN400 (16")-500(20^M)contain the standard of GB9112- 88, DIN2501, ISO2084 and Bs4504.

Main Material:

FAQ:

Q1. What is your payment term?
A: T/T 30% down payment, balance to be paid before shipment. or L/C.

Q2: What is your main market?
A: Western Europe, North America, Janpan,,

Q3: Can I get samples from your factory?
A: Yes, sample is free, but the express charge is yours.

Q4: If products have some quality problem, how would you deal with?
A: We will responsible for all the quality problems.

Q5.Are you manufacturer or trading company?
A.We are manufacture(cast iron) and trade company.

Q6. what’s the payment term?
A. We accept T/T, L/C,WESTERN UNION

Q7. What’s the delivery time ?
Pattern needs 30-60 days, sample need 30-50 days.
The first order need 60 days

Q8. What is the standard of package?
A. Export standard package or special package according to customer requirement.

Q9. Do you accept OEM business?
A. Yes, we are OEM supplier.

Q10. what kind of certificate you have ?
A .We have ISO9001, ISO14001,PED,SGS
