EPS Expander Machine Spare Parts Stainless Steel Angle Seat Valve

Categories Air Separator Generator Spare Parts
Brand Name: Chenrui
Model Number: CECA
Certification: ISO9001/ISO1400/18001
Place of Origin: France
MOQ: 1pcs
Price: USD 150-12000/pcs
Payment Terms: L/C, T/T
Supply Ability: 1000pcs PER DAY
Delivery Time: 10 days
Packaging Details: standard export packing
product: Fine Filter Element
life time: 1 year
application: psa oxygen/Nitrogen generator
Keyword: generator spare parts
Item: Spare parts
Material: Iron & Plastic
  • Haven't found right suppliers
  • Our buyer assistants can help you find the most suitable, 100% reliable suppliers from China.
  • And this service is free of charge.
  • we have buyer assistants who speak English, French, Spanish......and we are ready to help you anytime!
Submit Buying Request
  • Product Details
  • Company Profile

EPS Expander Machine Spare Parts Stainless Steel Angle Seat Valve

EPS Expander Machine Spare Parts Stainless Steel Angle Seat Valve


Angle seat valve Technical Data:

Fluid Pressure: Max×1.6MPa(232psi)

Control Pressure: 0.3-0.8MPa(43.5-116psi)

Control Fluid: Neutral gas, Air

Actuator Size: 50mm, 63mm, 80mm, 100mm, 125mm

Applicable Fluid: Water, Alcohol, Oil, Dye, Steam, Neutral gas or liquid, Organic solvent, Acid and lye

Fluid temperature: -10℃~180℃,25℃~220℃

Ambient temperature:-10℃~80℃

Control Type:Normally closed or Normally open

Connection for options: Threaded(BSP.BSPT,NPT), Welded, Flanged, Tri-clamp


Main Materials for angle seat valve:

Body Material: CF8(SS304) Or CF8M(SS316)

Seals Material: PTFE

Actuator Material: PPS or SS304


Angle seat valve Applications:

Beer& Drink Filling Machinery

Textile printing & Dyeing
Gas industry

Pharmacy & Medical Equipment

Chemical industry
Disinfection
Frothing Equipment
Water sewage Disposal


Advantages of angle seat valve:

1.Large Flux, low Resistance, No Water-hammer Y-type Shape Enlarged The Flowing Section, which Could Raise The Flux By 30% And Make Flow More Smooth.
2.Super Long Life.
3.Which Help The Stem Adjust And Lubricate Itself Automatically.

Product Details

DN15 industrial PTFE SEAT SS304 double action gas spring Angle Seat Valve

Female Thread Angle Seat Valve Outline Dimension

SizePort DInner boreABCΦEFHLMNA/F
DN13G 3/81365137125336113702102422
DN15G 1/21585170166342145802222428
DN20G 3/42095176166342150902322434
DN25G1251052101880541821002802441
DN32G1 1/4321202221880541921162922448
DN40G1 1/2401302352080541981303082455
DN50G25015026620100602281553502469
DN65G2 1/26518533020126732601704803086

DN80

G375220393271568734322051030100

Female Thread Angle Seat Valve Technical Parameters


SizePort C
(inch)

Inner

diameter
(mm)

KV Value

(m³/h)

working

pressure
(bar)

Required min.

contorl

pressure
(bar)

Executive

standard

(diameter mm)

DN13G 3/813.03.725.04.040
DN15G 1/213.04.225.04.050
DN20G 3/420.08.025.04.050
DN25G125.019.025.04.063
DN32G1 1/432.027.525.04.063
DN40G1 1/240.042.025.04.063
DN50G250.052.025.04.080
DN65G2 1/265.077.025.04.0100
DN80G375.025.04.0125

FAQ:

1. Are you manufacturer or Trade Company?
We are the manufacturer of Oxygen Generator, founded in 2005
2. What's the order oxygen generator process?
a. Inquiry---provide us all clear requirements.
b. Quotation---official quotation form with all clear specifications.
c. Contract confirmation---provide correct contract details.
d. Payment terms
e. Production
f. Shipping
g. Installation and commissioning

3. What terms of payment you use?
T/T, L/C etc.
4. How to get a prompt quotation of Oxygen Generator?
When you send the inquiry to us, pls kindly send it with below technical information.
1) O2 flow rate: _____Nm3/hr( or How many cylinders do you want to fill per day(24hours))
2) O2 purity: _____%
3) O2 discharge pressure: _____Bar
4) Voltages and Frequency : ______V/PH/HZ
5) Application:

6) Project Location:
