| Categories | High Voltage Fuse |
|---|---|
| Brand Name: | Julun |
| Model Number: | HV640 |
| Certification: | CE/UL/VDE/KC/ROHS |
| Place of Origin: | CHINA |
| MOQ: | 100 / Negotiable |
| Price: | Negotiable |
| Payment Terms: | L/C, D/P, T/T, |
| Supply Ability: | 10000/Piece/Weekly |
| Delivery Time: | 7~10 Working days |
| Packaging Details: | Standard carton |
| Rated Voltage: | 600VAC / DC |
| Rated Current: | 15A ~ 30A |
| Dimension: | 6*32mm |
| Material: | Ceramic |
| Breaking capacity: | Fast |
| Company Info. |
| JULUN (H.K)CO.,LTD (DONGGUAN JULUN ELECTRONICS CO.,LTD) |
| Verified Supplier |
| View Contact Details |
| Product List |
660 VAC / DC 6x32mm High Voltage Fuse HV640 Series Quick Acting Fuse
Fast Acting, high breaking capacity under 660V
Special Engineering Material tube, Silver plated cap construction
High breaking capacity for high energy application
RoHS and Lead Free material
| Electrical Characteristics | |
| 2.0In | 5 minutes, Maximum |
| 3.0In | 10 Seconds, Maximum |
| Part No. | Rated Voltage(V) | Rated Current | Breaking Capacity (A) | Typical Cold. Resistance (mOhms) | TypicalPre-Arcing I2t(A2Sec) | ||
| HV640.15 | 660V AC/DC | 15 | 1000 | 7.3 | 66 | ||
| HV640.16 | 16 | 7.3 | 62 | ||||
| HV640.20 | 20 | 5.5 | 120 | ||||
| HV640.25 | 25 | 4.6 | 200 | ||||
| HV640.30 | 30 | 3.7 | 270 | ||||
* DC Cold Resistance are measured at <10% of rated current in
ambient temperature of 25℃
* Typical Pre-arcing I2t are measured at 10In Current
1.What is your MOQ?
A: We provide you small MOQ for each item, it depends your specific
order.
2.What is your delivery date?
A: The delivery date is about 2-7days after receipt of payment.
3.What is your payment terms?
A: We accept T/T, western union, ,70% deposit in advance and 30%
balance before shipment.
4.Can you send free samples?
A: Yes, free samples are available; you just need to pay the
express fee. You can provide your a/c like DHL, or you can call
your courier to pick up from our office.
5.How do you carry out quality control?
A: Quality is our priority. Our QC always attach great importance
to quality control from the very beginning to the end.
6.Can you accept OEM orders?
A: Yes, we accept OEM & ODM orders, welcome all types of customized
orders and cooperation.
Please tell me:
What product specifications do you need? when you ask for a
quotation.I will give you the most competitive price per as your
requirements. And we have many types for you to choose.
P.S.:If you can't find any products to meet your requirements.
welcome to send us the details drawings so that we can provide us
our professional & best service to you.
|
