Categories | Gabion Mesh Machine |
---|---|
Brand Name: | DIAOZHUO |
Model Number: | DZ60X80 DZ80X100 DZ100X120 DZ66X88 DZ64X85 |
Certification: | CE ISO9001 |
Place of Origin: | HEBEI, CHINA |
MOQ: | 1set |
Price: | variable |
Payment Terms: | L/C, D/P, T/T |
Supply Ability: | 10 sets per month |
Delivery Time: | 20-30 days |
Packaging Details: | woodencase and plastic bags |
Material: | steel welding |
control: | automatic stop and counter |
speed: | 225-265m per hour |
engineer: | abroad avaliable |
product name: | gabion mesh machine |
mesh oepning: | 80x100 100x120 |
Heavy Duty Hexagonal Gabion Box Machine Automatic Gabion Production Line 2 x 1 x 1M
machine details
Model | Mesh Size(mm) | Max. Width(mm) | Wire diameter(mm) | Twisting Number | Main Drive Shaft Speed(r/min) | Motor Capacity(KW) | Theoretical Speed(m/h) |
LNWL23-60-2 | 60*80 | 2300 | 1.6-3.0 | 3 | 25 | 11 | 165 |
LNWL23-80-2 | 80*100 | 1.6-3.0 | 195 | ||||
LNWL23-100-2 | 100*120 | 1.6-3.5 | 225 | ||||
LNWL23-1200-2 | 120*150 | 1.6-3.2 | 20 | 255 | |||
LNWL33-60-2 | 60*80 | 3300 | 1.6-2.8 | 25 | 15 | 165 | |
LNWL33-80-2 | 80*100 | 1.6-3.0 | 195 | ||||
LNWL33-100-2 | 100*120 | 1.6-3.2 | 225 | ||||
LNWL33-120-2 | 120*150 | 1.6-3.5 | 20 | 255 | |||
LNWL43-60-2 | 60*80 | 4300 | 1.6-2.8 | 25 | 22 | 165 | |
LNWL43-80-2 | 80*100 | 1.6-3.0 | 195 | ||||
LNWL43-100-2 | 100*120 | 1.6-3.0 | 225 | ||||
LNWL43-120-2 | 120*150 | 1.6-3.2 | 20 | 255 | |||
LNWL43-60-3 | 60*80 | 4300 | 1.6-2.8 | 5 | 25 | 2 | 165 |
LNWL43-80-3 | 80*100 | 1.6-3.0 | 195 | ||||
LNWL43-100-3 | 100*!20 | 1.6-3.0 | 225 | ||||
LNWL43-120-3 | 120*150 | 1.6-3.2 | 20 | 255 |
Advantages:
1. CE / TUV certificate.
2. QC system & timely delivery.
3. New drive mode.
4. Automatic oil system.
5. Overload protect clutch.
6. High-efficiency: theoretic output = 3.5m/min.
7. Turbine protection system (Option).
8. Infrared ray safety (Option).
9. Automatic stop system (Option).
10. All of the core parts of machines are processed by our own
factory, so the quality can be ensured.
11. KONSON offer better after-sale service. We can provide 12
months guarantee for all the equipments,
we will arrange our engineer to install the machines in your factory and teach your workers how to produce, we will also send accessories and spare parts without any cost.
![]() |
