| Categories | Stainless Steel Filter Housing |
|---|---|
| Brand Name: | UPK |
| Model Number: | U019 |
| Certification: | SGS |
| Place of Origin: | CHINA |
| MOQ: | 1 Pc |
| Price: | Negotiation |
| Payment Terms: | L/C, T/T, Paypal |
| Supply Ability: | 2000 Pcs per month |
| Delivery Time: | 20-30 Days |
| Packaging Details: | 1 PC Per wooden box |
| Item Name: | Sanitary filter housing |
| Material: | 304 316L |
| Cores: | 3, 5, 7, 9, etc. |
| Inlet & Outlet: | Flange, quick-coupler |
| Application: | Sterilization filtration |
| Others: | MTO |
| Company Info. |
| Upick Filtration |
| View Contact Details |
| Product List |
Multiple cores series sanitary grade liquid stainless steel filter housing
Specification
Table 1, Surface Treatment
| Polishing Type | Physical / Electro / Grit Blast |
| Polishing Rating | I-0.3μm / O-0.4μm |
Table 2, Operational Environment
| Pressure | 0.6Mpa (6bar) |
| Max Temp. | 130℃ (266℉) |
| Sterilization | 121℃/30Min. |
Table 3, Material
| Housing | 304, 316L |
| Vent/Drain Valve | 304, 316L |
| Tri-Clasp | 304 |
| Stand Bar | 304 |
| O-ring/Gasket | Silicone, Viton, EPDM, PTFE |
Table 4, Connection
| Cylinder | Flange |
| Inlet/outlet | Quick coupler |
| Vent | 1/4” valve |
| Drain | 1/4” valve |
| Gauge | 1 1/2” Fast clasp |
Application
TMFH series are wildly used in water treatment, food & beverage, chemical, pharmacy, etc. industries, in order to meet different industry need, it also can be degrade to industrial grade via grit blast surface treatment.
Feature & Benefits
Ordering Information
|
