CNC Repeating Precision Sample Cutting Machine For Corrugated Board Box

Categories Corrugated Box Making Machine
Brand Name: MAXWELL CUT
Model Number: MEC
Certification: CE
Place of Origin: SHANGHAI CHINA
MOQ: 1 units
Price: up to the sizes
Payment Terms: TT, WU, Paypal
Supply Ability: 30 sets per month
Delivery Time: within one month after we get the order
Packaging Details: wooden boxes
Product Name: sample box MAKING machine
Model: M-702516
Effective cutting area: 2500*1600mm
Max aped: 1400mm/s
Smallest cutting diameter: 6mm
Maximum cutting thickness: 60mm
Cutting Materials: foam, EVA, PVC,PP Sheets, polypropylene corrugated sheet ,corrugated cardboard up to 60 mm, cartons, laminates, printing blankets, coating plates, preprinted vinyl films, reflective sheeting, textile and technical fabrics, soft,
Cutting thickness: less than 100mm
Size: 1300*1000mm, 1800*1500mm, 2500*1600mm, 3000*1600mm, 3000*2000mm, customerised
tools: oscillating knife, Creasing wheel, Pen, laser light,
Tools: Pneumatic tool, Vcut, Kiss Cut, CCD
TABLE: Flatbed, Conveybelt,
  • Haven't found right suppliers
  • Our buyer assistants can help you find the most suitable, 100% reliable suppliers from China.
  • And this service is free of charge.
  • we have buyer assistants who speak English, French, Spanish......and we are ready to help you anytime!
Submit Buying Request
  • Product Details
  • Company Profile

CNC Repeating Precision Sample Cutting Machine For Corrugated Board Box

corrugated paper sample box cutting machine for package and priNT


The machines have the machines have three types of functional heads: vibration cutting head, creasing wheels, V-Cutter, high speed milling Router, with drawing pen. It enable the machine can work on different materials; corrugated paper, gray board, white cardboard, plastic sheets, composite materials, textiles, leathers, foam board, sponge etc at option of 15mm maximum cutting height.


Operation propertiesComputer operation and cutting machines can be used simultaneously for quick data transmission capable of continuous operations
Cutting speedMaxi 1500mm/s
Cutting Thickness0.5-15mm
Cut materialsIvory cardboard,gray paper,corrugated paper,plastic sheets, composite materials and leather materials, rubber,Plastic corrugated sponge and foam board.
Number of pens8 different groups of strokes,half blades,full blades and pressure wheel setup, Drawing pen
Positioning deviceRed Ultra-Light / CCD camera head positioning
Method for fixing paperVacuum absorption
Cutting tolerance±0.2mm
Repeat accuracy0.05mm
Minimum circle5mm diameter
Transmission interfaceEthernet port
Format compatibleCompatibility format AI software,Auto cad,Coraldraw and all box software
Direcive systemHP-GL and GP-GL
Digital control panelLiquid crystal display and contact button
Transmission materialsStraight-line guide rails and imported synchronous belts
Supply voltageAC 220V 380V ±10%,50HZ
Vibration bladeVibration cutter head motor at 25000rpm

1.Accurate

High requirement of ourselves and persistent striving for excellent, lead to high accuracy. With our laser

location device and other elaborate devices the cutting machine meets the cutting precision: 0.3mm to 0.5mm.


2.Smooth

The Oscillating Cutting Tool assures our cutting machines cut smoothly. Even very complex lines, irregular lins,can be cut smoothly.

And this cutting effects can hardly be done by laser cutting machine, die cutter or manual workers.


3.Diverse

Material -- It can cut nearly all of soft materials and some hard materials.
The Cutting thickness -- 0.4mm to 55mm, even larger, according to the material and your requirement.
Function -- complete cutting, half cutting, dot cutting, V- cutting; line folding; marking.


4.Exquisite

The cutting machine is able to cut complex patterns with high precision and repeating precision.
