| Brand Name: | LIYI |
| Model Number: | LY-280 |
| Certification: | CE,ISO |
| Place of Origin: | Dongguan , China |
| MOQ: | 1 set |
| Price: | USD 5000-10000 / 1 set |
| Payment Terms: | T/T, Western Union, L/C, , D/A, D/P, MoneyGram |
| Supply Ability: | 100 sets per one month |
| Delivery Time: | 10-20 working days |
| Packaging Details: | glue wooden box |
| Material: | Steel |
| Size: | Customized |
| Temperature: | -40℃~150℃ |
| Humidity: | 20%~98% customizied |
| Color: | Customized |
| Controller: | imported Tecumseh compressor |
| Certificate: | CE,ISO |
| Power: | 220VAC±10% 50/60Hz |
| Standard: | IEC60068-2-1 |
| Accuracy / volatility: | ±1.0 degree ±2.0%R.H. / ±0.5 degree ±2.0%R.H. |
| Company Info. |
| Dongguan Liyi Environmental Technology Co., Ltd. |
| Verified Supplier |
| View Contact Details |
| Product List |
Narrow Type Painted Temperature Humidity Chambers
Application:
This Chamber can simulate different environment condition. It's appropriate for testing material performance, such as resist heat, resist dry,resist humidity and resist cold. That can define performance of material.
Product Description:
Inspect standard:JJF-1101,GB/T 10592,GB/T 10586
Testing standards:YD/T 2061,HB 7122.3,6783.7,GJB 5382.7,GJB 150,GB/T 2423,5170.2,5170.5,5179.2, ASTM E512,NF EN 60068-2-38,CNS 12565,12566,KS C0227,KS C022
| Model | LY-280 | LY-2150 | LY-2225 | LY-2408 | LY-2800 | |
Inner Size W×H×D(cm) | 40×50×40 | 50×60×50 | 50×75×60 | 60×85×80 | 100×100×80 | |
Outside Size W×H×D(cm) | 93×155×95 | 100×148×106 | 117×166×91 | 140×176×101 | 170×186×111 | |
| Volume (V) | 80 L | 150L | 225L | 408L | 800L | |
| Temp and Hum Range | A:-20°C~150°C B: -40°C~150°C C: -60°C~150°C D: -70°C~150°C RH20%-98% | |||||
| Function | Fluctuation | ±0.5°C ±2.5%RH | ||||
| Deviation | ±0.5°C-±2°C ±3%RH(>75%RH); ±5%RH(≤75%RH) | |||||
Controller Analytical Accuracy | ±0.3°C ±2.5%RH | |||||
| Wind Cycling Way | Centrifugal fan-broadband type forced air circulation | |||||
| Refrigeration Way | Single stage compression refrigeration | |||||
| Refrigerator | French Tecumseh | |||||
| Refrigerants | R4O4A USA DuPont environmental protection refrigerant(R23+R404) | |||||
| Condensing Way | Air-cooled or water-cooled | |||||
| Water Supplying Way | Automatic cycling water supply | |||||
| Standard Accessories | 1 Observe window(double-deck cavity toughened glass), 1 50mm test hole in the left, 1 PL inner chamber lamp, 2 clapboards, 1 bag of wet and dry bulb, 3 fuses, 1 power line. | |||||
| Safety device | Non- fuse-switch(compressor overload, refrigerant high low voltage, over-humidity and temperature protection, Protection switch,fuse stoppage warning system | |||||
During the whole business process, we offer Consultative Selling service.
1)Customer inquiry process:
Discussing testing requirements and technic details, suggested suitable products to customer to confirm. Then quote most suitable price according to customer requirements.
2)Specifications customize process:
Drawing related drawings to confirm with customer for customized requirements. Offer reference photoes to show the proucts appearance. Then, confirm the final solution and confirm final price with customer.
3)Production and delivery process:
We will produce the machines according to confirmed PO requirements. Offering photoes to show production process.
After finish production, offer photoes to customer to confirm again with the machine. Then do own factory calibration or third party calibration(as customer requirements). Check and test all the details and then arrange packing.
Deliver the products in confirmed shipping time and inform customer.
4)Installation and after sale service:
Defines installing those products in the field and providing after-sales support.
|
