| Categories | Small Cargo Truck |
|---|---|
| Brand Name: | SINOTRUK HOWO |
| Model Number: | ZZ1167M5011V |
| Certification: | ISO/CCC |
| Place of Origin: | China |
| MOQ: | 1set |
| Price: | USD29000-39000/set |
| Payment Terms: | L/C, T/T, Western Union |
| Supply Ability: | 500sets/month |
| Delivery Time: | 15-30 work days after receiving deposite |
| Packaging Details: | Packaing suitable for sea transport |
| Product Name: | Cargo Truck |
| Application: | Cargo Transportation |
| Drive Type: | 6*4 |
| Hose power: | 290hp |
| Cabin: | HW79 cab |
| Payload: | 10ton |
| Color: | Optional |
Specifications:
| Typical vehicle model | ZZ1167M5011V | ||
| Cab | Model | HW79 | |
| Type | High roof cab,doubleberth,air suspension drivers seat,up/down and front/back adjustable steering wheel, VDO instrument and control module,safety belt with double locking mechanism,exterior sun visor | ||
| Engine | Model | WD615.87 | |
| Reted power(kw/rpm) | 213/2200 | ||
| Max torque(Nm/rpm) | 1160/1100-1600 | ||
| Displacement/L | 9.726 | ||
| Type | Inline 6cylinders,supercharged intercooling,central superchanger,electronic high pressure and common rail | ||
| Cluch | 430diaphragm-springclutch,hydraulicallycontrol air power assisted.Standard 430A type for D10.38,D12.38 and D12.42 engine, and standard 430B type for D10.34. | ||
| Transmission | SINOTRUK HW series 10 speed transmission, main and auxiliary transmission structure, main transmission with double countershaft, auxiliary transmission with planetary reducer. Standard HW19710 for D10.34,D10.38,D12.38 and D12.42 engine;optional HW19710T with synchronizer. | ||
| Front axle | HF7, rated load of 7t, disc-type or drum-type | ||
| Rear drive axle | ST16 double reduction(central reduction+wheel reduction) speed ratio 4.42; 4.8 | ||
| Suspension | Front and rear leaf spring suspension, front suspension with shock absorber, transverse, rear suspension is disconnected type with transverse stabilizer. | ||
| Steering system | ZF8098 steering box,ZF steering oil pump , system pressure of 18 MPa | ||
| Brake system | Service brake: dual-circuit air pressure brake; energey storage spring air cutoff brake; engine exhaust brake; Optional EVB, ABS and automatic slack adjuster. | ||
| Electrical system | CAN bus control, voltage:24V; generator :2240W; starter:7.5kw; battery:12V/165Ah,2 pieces | ||
| Tyre | 315/80R22.5;12.00R20 | ||
| Tank volume/L | Standard 400L, optional 600L | ||
| Kerb weight (vechicle / chassis)/kg | 8800 | ||
| Gross mass/kg | 18000 | ||
| Authorized max towed mass/kg | 35000 | ||
| External dimensions(length*width*hright)/mm | 8770x2496x3850 | ||
| Wheelbase/mm | 3500 | ||
| Front/rear overhang/mm | 1540/1120 | ||
| Wheel track(front/rear)/mm | 2022/1830 | ||
| Min ground clearance/mm | 314 | ||
| Approach/departure angle | 15/46 | ||
| Max speed/(km/h) | 100 | ||
| Max packing slope/% | 20 | ||
| Min turning diameter/m | 15 | ||
| Ground clearance of fifth wheel joint face(unload)/mm | 1390 | ||
| Front/rear turning radius / mm | 2460/2250 | ||
| Traction pin specifiction | 50#(2 in.) / 90# | ||
Description:
We have customers from worldwide countries and areas, such as Kenya, Ethiopia, Libya, Turkmenistan, Kazakhstan, South Africa, Syria, middle-east,African, South-African, Australian and so forth. We serve the best service for our customers.Welcome all friends come to visit our factory. The series products of our trucks are ideal versions instead of imported ones. With outstanding performance and high quality, they are widely used in industries and sectors, such as national defense, aviation, postal service,
railways, highways, harbors, petroleum, chemicals, water and electricity, forests, fire fighting, banks
and peace keeping forces. The machine is designed with both hand and automatic controls system
with the specialties of large volume, high efficiency, better sealing and easy for service so that they are widely used in municipal refuse handling, commercial and industrial garbage operations.
Applications:
The cargo truck is mainly used to transport small quantities of food, industrial goods for daily use, and other goods. Some are made into dual purpose vehicles. Due to high thermal efficiency, the diesel engine is adopted by heavy-duty cargo vehicle. In addition, more and more medium-duty and light-duty cargo vehicles begin to use diesel engines.
Competitive Advantage:
1. The satisfied product with high level standard;
2. The full aspect service from order to shipping;
3. Give customer most suitable advice when customer has special needs for your transportation or construction;
4. Help customer to get the related spare parts of trailer or tractors if customer needs.
we are waiting for you to get this ideal products and best service.
|
