6 " Low Carbon Galvanized Water Well Screen High Temperature Resistant

Categories Water Well Screen
Brand Name: HengYuan
Model Number: HY-16
Certification: ISO
Place of Origin: Hebei,China
MOQ: 6 " Low Carbon Galvanized Water Well Screen,Johnson Type Water Well Screen
Price: negotiated price
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability: 1500 pcs /month
Delivery Time: 7 days
Packaging Details: wooden boxes ,container
Name: 6 " Low Carbon Galvanized Water Well Screen
Material: low carbon galvanized ,stainless steel
Length: 2.9m,5.8m etc.
Diameter: 2 ", 3 " ,4 " ,6 " ,8 " ,10 " ,12 " ,14 " ,16 " and so on
Technique: point welding
Features: non-clogging
Application: filteration
Package: wooden boxes,container
  • Haven't found right suppliers
  • Our buyer assistants can help you find the most suitable, 100% reliable suppliers from China.
  • And this service is free of charge.
  • we have buyer assistants who speak English, French, Spanish......and we are ready to help you anytime!
  • Submit Buying Request
    • Product Details
    • Company Profile

    6 " Low Carbon Galvanized Water Well Screen High Temperature Resistant

    6 " Low Carbon Galvanized Water Well Screen,Johnson Type Water Well Screen


    Johnson v wire water well screen is manufactured by a v or wedge shaped wire around an internal array of longitudinal support rods. Each intersecting point of these wire is fusion welded.
    The v or wedge shaped profile wire wraps around the support rods over the full length of the screen creating a continuous slot opening, hence the screen allows water (oil) to enter your well freely in ample quantities,while at the same time keeps the majority of sand and gravel out of the well.

    Water well screen pipe is made up of Vee-shaped wire and round rod in each intersection welded together.
    Each slot opening between adjacent wires is V-shaped, resulting from the special shape of the wire used to form the screen surface.
    The V-shaped openings, designed to be non-clogging, are narrowest at the outer face and widen inwardly.It has the firm structure, high temperature resistant, corrosion resistance, good mechanical performance, long service life, safe and reliable, etc.
    It also can be used for a variety of medium.


    Slot Size (mm): 0.10, 0.15, 0.2,0.25, 0.30-3 or as per customers’ requirement
    Material of this Johnson screen:
    Johnson screen can be produced with SS 304, 304L, 316, 316L or carbon steel
    Unit length up to 6m.
    Diameter from 25mm to 1200mm
    Open area up to 60%
    End Connection: beveled or thread coupling


    Basepipe OD (in)
    Perforations per foot
    Basepipe Hole Size (in)
    Open Area of Basepipe Holes (in2/ft)
    Wrap Wire Size Keystone (in)
    Rib Wire Size Round (in)
    Maximum OD (in)
    1.05
    54
    0.312
    4.14
    0.09*0.09
    0.125
    1.489
    1.315
    66
    0.312
    5.06
    0.09*0.09
    0.125
    1.726
    1.66
    78
    0.312
    5.98
    0.09*0.09
    0.125
    2.126
    1.90
    42
    0.375
    4.63
    0.09*0.09
    0.125
    2.387
    2.063
    42
    0.375
    4.63
    0.09*0.09
    0.125
    2.55
    2.375
    54
    0.375
    5.96
    0.09*0.09
    0.125
    2.86
    2.875
    66
    0.375
    7.28
    0.09*0.09
    0.125
    3.362
    3.25
    78
    0.375
    8.61
    0.09*0.09
    0.125
    3.737
    3.50
    78
    0.375
    8.61
    0.09*0.09
    0.125
    3.987
    4.00
    90
    0.375
    9.94
    0.09*0.09
    0.125
    4.487
    4.50
    102
    0.375
    11.26
    0.09*0.09
    0.125
    5.001
    5.00
    114
    0.375
    12.59
    0.09*0.09
    0.125
    5.506

    If you have any enquires please feel free to contact us !


    Our factory Hengyuan hardware netting industry product co.,ltd located in Anping country , Hebei Province , China.

    Our mainly products are : stainless steel vee sharped wire / wrap wire,johnson screeen , water well screen / rod based wire wrapped screen , wedge wire screen pipe , reverse wedge wire screen,screen nozzle / water and gas strainer ,sieve plate ,slot mesh ,ARC screen ,header and hub laterals & hub radial laterals , pipe base , crimped wire mesh / stainless steel wire mesh / perforated wire mesh etc .
